Specifications
coal water slurry (CWSF) preparation line1.Continuous Working
2. Low ELectric consumption
3. Durable Equipment
1. Brief Introduction of Coal-water Slurry Benefit
Safe storage and transportation fuel: The presence of water in CWS reduces harmful emissions into the atmosphere and makes the coal explosion-proof. By converting the coal into a liquid form, delivery and dispensing of the fuel can be simplified.
Low cost fuel: Because of the relatively low cost of coal when compared to other energy sources, CWS is a very competitive alternative to heating oil and gas. Depending on geographical area the price per unit energy of CWS may be 30% to 70% lower than the equivalent oil or gas.
Cost effective and environmental friendly: Low emissions and low BTU cost (Gcal or MWh) make CWS very cost effective and environmental friendly fuel for heat and power generation.
2..Flowchart for Syatem Equipment Allocation of CWM Production Line
3.CWS Production Line Technical Parameter
Model |
Annual |
Quantity |
Outline Dimension |
Mill Medium |
Power |
Applicable Coal |
||
BCWS-5 |
5 |
*104(t) |
1 |
UNIT |
Φ2200mm× 7500mm |
34t |
380kw |
Cleaned Coal, |
BCWS-10 |
10 |
*104(t) |
1 |
UNIT |
Φ2200mm× 11000mm |
37t |
570kw |
|
BCWS-15 |
15 |
*104(t) |
1 |
UNIT |
Φ2600mm× 11000mm |
49t |
800kw |
|
BCWS-20 |
20 |
*104(t) |
1 |
UNIT |
Φ3000mm× 9000mm |
63t |
1000kw |
|
BCWS-30 |
30 |
*104(t) |
1 |
UNIT |
Φ3000mm× 11000mm |
70t |
1250kw |
|
BCWS-50 |
50 |
*104(t) |
1 |
UNIT |
Φ3200mm× 14000mm |
97t |
1800kw |
|
Note: fuel consumption is based on calorific value of Coal-water slurry is 42000KJ/Kg
