DPP-250A Aluminum Plastic Blister Packing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Medical, Other, Food, Medical, Machinery & Hardware
Automatic Grade:
Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DPP-140E Double Aluminum Capsule Blister Packing Machine Pharmaceutical LineNegotiableMOQ: 1 Set -
DPP-500H Blister Hardware Packing MachineNegotiableMOQ: 1 Set
-
DPP-250A Medical Packaging MachineNegotiableMOQ: 1 Set
-
Model DPP-250E Plane Hard Double Aluminum Blister Packaging Machine( Pharmaceutical Packing Machine)NegotiableMOQ: 1 Set
-
Blister Pen Packing Machine/blister Packaging MachineNegotiableMOQ: 1 Set
Condition
New
Application
Food, Medical, Other, Food, Medical, Machinery & Hardware
Automatic Grade
Automatic
Driven Type
Electric
Voltage
220v/380v 50HZ
Power
5.5KW
Place of Origin
Zhejiang, China
Brand Name
huayuan
Model Number
DPP-250A
Dimension(L*W*H)
2800*650*1400mm
Weight
1200KG
Certification
CE
Warranty
1year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.Stainless steel 3162.PLC and color touch screen
3. For all kinds of shape of solid and liquid packing
4.Capacity:14000p
Applications:
The machine is new product which is improved based on customers requirements. Its suitable for packaging of all kinds of liquid and solid in large & medium pharmaceutical factory, health medicine factory, hospital preparation lab, food industry, electronic industry, hardware industry, etc. It can protect the material from steam or dust, improve product packing degree, and increase the additional value. The machine is used to produce large quality and single product.
Performance and characteristic:
- Travel scope can be adjusted.
- Mould is located by locating groove which makes it easy to change mould. The machine heats the PVC through conduction and forms it through pressing and frothing.
- The material is fed automatically. The mould and feeder can be designed as users requirements.
- Speed is shifted by step-less transducer. Adopt the interface of human-machine and PLC programmable controller, it can synchronize accurately.
- Adopt the equipment of trace pressing, batch number printing and scarp-collecting.
- Manipulator grip to tow wrapper, straight to-and-fro running. Synchronize accurately. (Stepping motor can be chose to drive and tow wrapper)
- The heating moulds will automatically separate when the machine stops, which contributes to protect the material between them and extend the machines life.
Main Technical Parameter:
MODEL 250A Blanking frequency(sheets) 15-60 Sheet's quantity of one blanking(sheets) 3-4 Capacity:(sheets/hour) 3600-14400 Adjustable scope of feed travel:(mm) 10-160 Max Forming area and depth:(mm) PVC(For medicine): 250×160×25 Capacity of air compressor(m3/min) ≥0.36 Power supply:(KW) 380V 50HZ 5.5KW Wrapper specification(mm) PVC for medicine 250×(0.15-0.5) PTP Aluminum film 250×(0.02-0.035) Overall dimensions (mm) 2800×650×1400 Part sizemm 1400×650×1400 1400×650×1400 Weight(kg) 1200
