Specifications
1.has CE. ISO certificate2.high output
3.brand-name parts
4.servo drive
Auto blow molding machine is link with Germanic technology, we are specializing in producing and selling Plastic blow molding machine, such as plastic bottle, tank, Jerrycans, toolbox, abnormal blow molding piece, motorcar oil box, tray, etc., which is range from 10ML to 220L.
We supply single, double, multi-mould and single, double layers, multi-layers composite mould according to the customers requirements. We have lots of experiences in this line for ten years, we possess large number of skilled workers and technical stuffs which has fruitful practice experience, and also they have assembling` and servicing for more than two thousand consumers.
| Specifications | TJ-ZKS80 | |
| Material | PE,PP,PA,ABS... | |
| Max.capacity of product | L | 10 |
| Dimensions(L*W*H) | m | 3.8*2.3*3.1 |
| Total weight(approx) | T | 8.3 |
| Dia. of main screw | mm | 80 |
| L/D ratio of screw | L/D | 25 |
| Quantity of die heating zones | zone | 4 |
| Heating power of die(approx) | KW | 5.6 |
| Center distance of double-die | mm | 240 |
| Max. dia. of die | mm | 140 |
| Clamping force | KN | 110 |
| Distance between platens | mm | 240-620 |
| Max. size of mould(W*H) | mm | 470*490 |
| Driving power of main extruder | KW | 37 |
| Motor power of oil pump | KW | 11 |
| Total power(approx) | KW | 62 |
| Water pressure | Mpa | 0.3 |
| Water consumption | L/min | 60 |
| Air pressure | Mpa | 0.6 |
| Air consumption | m3/min | 0.8 |
| Average energy consumption(approx) | KW | 45 |
International experienced engineering team:
Permanent consultant : Mr. Schulz (Germany)
Our main customers :
