AEROFLEX-IFR 2398 Spectrum Analyzer 9KHz-2.7GHz

•Frequency Tuning Range: 9 kHz to 2.7 GHz.

•Tuning Resolution. 1 Hz.

•Frequency Span Width: 100 Hz/div to 270 MHZ/div in 1, 2, 5 step selections (auto selected) plus ZERO Span, and FULL Span (9 kHz to 2.7 GHz). Manual selection of start, stop, and span.

•Span Accuracy: ± 3% of the indicated span width.

•Readout Accuracy: Span accuracy + frequency standard accuracy + 50% of RBW.

•Frequency Counter Resolution: 1 Hz, 10 Hz, 100 Hz and 1 kHz.

•Accuracy: ± (Reference frequency error x marker frequency + counter resolution ± 1 count).

•Sensitivity: <= -70 dBm. Amplitude Measurement Range: +20 to -105 dBm.

•Frequency Range: 9 kHz to 2.7 GHz.

•Displayed Average Noise Level: (1 MHz to 2.7 GHz, Resolution bandwidth of 300 Hz, 10 Hz video filter) -105 dBm. Sweep Rate (full screen): 50 ms to 1000 sec (in 1-2-5 sequence).

•Display: (7.4 in) Monochrome LCD.

  Packing:

• Carton packing
• Pack the instrument with PE bubble bag
• Foam-in-place to protect the instrument
• Fasten the carton with Belt
• Pack the carton with PE film to waterproof

• 30days warranty, No ROR
• During the warranty date, the buyer can return the item if have quality problem.
• If you want to return the instruments, the return item has to be the original packing. Without my permission, the instrument cannot be dismantled.
• You are responsible for returning the item and paying for return shipping. The payment for the freight cost will not return. Only payment for the instrument will be refund.
• The refund will complete within 7 working days after we receive the return items
