FU2200A Electricity wireless energy monitor meter
Introduction
The FU2200A digital power meter is a range of economical yet highly functional three-phase multifunction power and energy meters manufactured by GFUVE. These meters provide excellent value for monitoring power and energy management systems. The 2200A digital power meter may be used as data gathering devices for intelligent power distribution or plant automation systems. All monitored data is available via a standard digital RS485 communication port running the Modbus RTU protocol. With a wide range of models to choose from, the 2200A digital power meter offers unparalleled value and functionality.
Features
- True-RMS measuring Parameters.
- ANSI and IEC 0.5 Accuracy class.
- Power Quality Analysis.
- 4 Quadrant Energy;
- 4MB onboard memory;
- Data logging
- High-speed RS485, Ethernet Port (optional);
- Measure Individual Harmonics from 2nd to 63th (optional);
- Module Design;
- TOU, 4 Tariffs, 12 Seasons, 14 Schedules
- Class leading Warranty.
- With management software
Applications
- Metering of distribution feeders, transformers, generators, capacitor banks and motors.
- Medium and low voltage systems.
- Commercial, industrial, utility.
- Power quality analysis.
- Specifications
Parameter |
Accuracy |
Resolution |
Range |
|
Voltage |
0.2% |
0.01V |
0.5~500kV |
|
Current |
0.2% |
0.01mA |
5mA~50000A |
|
Active Power |
0.5% |
0.2W |
-9999MW~+9999MW |
|
Reactive Power |
2% |
0.2var |
-9999Mvar~+9999Mvar |
|
Apparent Power |
0.5% |
0.2VA |
0~9999MVA |
|
Active Power Demand |
0.5% |
0.2W |
-9999MW~+9999MW |
|
Reactive Power Demand |
2% |
0.2var |
-9999Mvar~+9999Mvar |
|
Apparent Power Demand |
0.5% |
0.2VA |
0~9999MVA |
|
Power Factor |
0.005 |
0.0001 |
-1.0000~0~1.0000 |
|
Frequency |
0.01Hz |
0.01Hz |
45.000~65.000Hz |
|
Energy |
Primary |
0.5% |
0.1kWh |
0~99999999.9kWh |
Secondary |
0.001kWh |
0~999999.999kWh |
||
Reactive Energy |
Primary |
2% |
0.1kvarh |
0~99999999.9kvarh |
Secondary |
0.001kvarh |
0~999999.999kvarh |
||
Apparent Energy |
Primary |
0.5% |
0.1VAh |
0~99999999.9kVAh |
Secondary |
0.001VAh |
0~999999.999kVAh |
||
Phase Angle |
0.1° |
0.01° |
0~359.99° |
|
Unbalance Factor |
2% |
0.01% |
0~300.00% |
|
PT |
|
1 |
1~10000 |
|
CT |
|
1 |
1~10000 |
|
Addr |
|
1 |
1~254 |
|
Current Input
Rated Current 5A/1A ac Measurement Range 0~6A ac
Overload capacity 20A continuous, 50A 10Sec, 100A 1Sec Burden 0.5VA @5A RMS
Current start 0.1%Rated value Accuracy 0.2%
Voltage Input
Rated voltage 400Vac L-N, 690Vac L-L Input Impedance 1MΩ per phase
Overload capacity 1500Vac continuous,2500Vac 50/60Hz 1min Frequency 45Hz~65Hz
Accuracy 0.2%
Energy Accuracy
Active class 0.5S (IEC62053-22,GB/T17215.322-2008)
Reactive class 2 (IEC62053-23)
Power Supply (AC/DC)
Range 85~265Vac,50/60Hz;100~300Vdc Power Consumption:5W
Insulation voltage capacity 2000Vac,50/60Hz,1min
Working condition
Operation Temperature -25°C~+70°C Storage Temperature -40°C~+85°C
Relative Humidity 5% ~ 95%( non-condensing)
