Help CenterVoltmeter Rotary Switch N-5
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
CANSEN
Model Number:
LW26
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo&Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pad-lock Switch LW26GS-125 ( CE Certificate)US$ 3 - 5MOQ: 100 Pieces -
Multi-step Rotary Cam Switch Multi - Terminals LW26 20A (CE Certificate)US$ 1.56 - 3.99MOQ: 100 Pieces
-
Rotary Switch With Plastic Box LW26-20A (CE Certificate)US$ 3 - 15MOQ: 100 Pieces
-
Cam Switch LW26 (ROHS,CE Certificate) With Single Hole InstallationNegotiableMOQ: 100 Pieces
-
Cansen Brand Switch (ROHS,CE Certificate)NegotiableMOQ: 100 Pieces
Place of Origin
Zhejiang, China
Brand Name
CANSEN
Model Number
LW26
Max. Current
20A
Max. Voltage
690V AC
Mechanical Life
10,000,000times
Specifications
productive history for 30 years,current range:20A
certificate:CE
Voltmeter rotary switch N-5
No. |
Tech Parameters |
requirement |
1. |
rated voltage |
below 690V |
2. |
rated current |
20A |
3. |
frequency |
AC50HZ |
4. |
No.of poles |
|
5. |
No.of layers |
3 layers |
6. |
panel size |
48*64mm |
7. |
colour of handle |
black, |
8. |
Working temperature |
-25°C~+40°C REMARKS:the average temperature mustn’t be pass 35°C |
9. |
Working height |
≤2,000m |
10. |
Relative humidity |
≤50% with highest temperature +40°C,but allow higher humidity with low temperature less than 40°C (eg.:humidity 90%----teperature20°C) |
11. |
Instalation conditions |
polution class III |
12. |
Mechanical life |
0.1*106times |
13. |
Electrical life |
0.03*106times |
14. |
Operative frequency |
120times/hour |
15. |
transform angle |
45° |
