Home > Products > Rotary Switch LW26 > cansen brand switch (ROHS,CE certificate)
cansen brand switch (ROHS,CE certificate)
Negotiable
/ Piece
100 Pieces(Min.Order)
- 300 Piece / Pieces per Month
- Ningbo&Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
- LJV RE09101AB-V01-0026 Incremental rotary encoder, 10 pulses, 20 positions, horizontal, with press switch, shaft length 15mm
- EC18/RE18 Digital Absolute Encoder Rotary Type For Wash Machine Control Panel,Logical encoder,12 Channel encoder
- EC16/RE16 incremental rotary encoder, 12 position/12 pulses, IP67 waterproof, without press switch
- RS126 double pole, double throw, Self -return switch,Reset Switch,Left and right rotation
- RS26 1 Pole Position 10 Selectable Band Rotary Channel Selector Switch
- RS12 gear switch Multi-position rotary switch 2 gear 4 gear audio semi-circular handle rotary switch
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | CANS | Model Number: | LW26 |
Max. Current: | 315A | Max. Voltage: | 440V&DC 240V | Mechanical Life: | 10,000,000times |
Product Description
Specifications
productive history for 30 years,current range:10A to 315A
certificate:Rohs&CE
IP class:IP65
No. | Tech Parameters | requirement |
1. | rated voltage | below 440V & DC220 |
2. | rated current | 10A,20A,25A,32A,63A,80A,100A,125A,160A |
3. | frequency | AC50HZ |
4. | No.of poles | 2P,3P,4P |
5. | No.of layers | make as required with circuit diagram |
6. | panel size | 30*30mm,48*48mm,64*64mm,88*88mm |
7. | colour of handle | black,white,red,grey |
8. | working temperature | -25°C~+40°C REMARKS:the average temperature mustn’t be pass 35°C) |
9. | Working height | ≤2,000m |
10. | Relative humidity | ≤50% with highest temperature +40°C,but allow higher humidity with low temperature less than 40°C (eg.:humidity 90%----teperature20°C) |
11. | Instalation conditions | polution class III |
12. | Mechanical life | 0.1*106times |
13. | Electrical life | 0.03*106times |
14. | Operative frequency | 120times/hour |
15. | transform angle | 30°/45°/60°/90°/120°/135°/150° |
