Specifications
7 inch lcd monitor with hdmi input1.AV,VGA
2.Wide view
3.8 years' experience
4.FCC/CE/ROHS
7 inch lcd monitor with hdmi input Touch Screen Monitor
7 inch lcd monitor with hdmi input Description:
1) 7 inch TFT touch screen monitor
3) Display type: 7" Active Matrix TFT LCD ( 16:9 )
4) Active display area: 152.4(H) X 91.44(V) mm
5) Resolution: 800 x 480 @ 60Hz / 1024 x 768 @ 75Hz max
7) Pixel pitch: 0.1905(W) X 0.1905(H) mm
8) Pixel response time: 12ms
9) Colors: 16.7 million
10) Brightness: 350 cd/m2
11) Contrast: 400:1
12) Viewing angle horizontal (left/right): 170° (85°/85°)
(From Centre, CR>=5) Vertical (up/down): 160° (70°/90°)
13) Backlight lamp life hours: 50,000
14) Input video format: Analog RGB, NTSC/PAL/SCAME(AUTO)
15) Touch screen Interface: USB
16) Touch response time Serial/USB: 10.4ms
17) Touch sensitivity: Fixed
18) Operating temperature:-10°C - 60°C
19) Storage temperature:-20°C - 80°C
20) Power Supply: AC 110-240V, DC 12V, 50-60 Hz
21) Power Consumption: <10 W Typ
22) Monitor Dimensions: 180*123*30mm
23) Packing Dimensions: 302*215*80mm
24) Gift box Weight: 1.5kg
25) Warranty: 1 year
26) Remote control
Specification for 7 inch lcd monitor with hdmi input:
1) 4 wires resistive touch-screen interface with high Sensitivity (USB port)
2) Standard VGA input (15 pin D-SUB/USB) can match with PC, GPS and security systems
3) 2 RCA video input can match with VCD, DVD and camera
4) RGB input
5) Touch-screen for PC display
6) Built-in speaker/amplifier and earphone jack
7) Operating Systems: DOS/Windows 9X, ME, 2K, XP, 7, Vista, NT, CE
/ LINUX / Mac,etc.
Accessories
1. USB cable
2. VGA cable
3. Remote controller
4. Home and car adapter
5. Software CD
6. English user manual
7. Touch Pen
8. Bracket
Transport method: We send the sample and small order by air express courier, such as DHL,UPS (door to door, 5-7 days) , China post ( cheapest cost with 15-25 days); We send the bulk order by normal air parcel ( airport to airport ) or ship ( 15-25 days ).
1. Quick and accurate reply with best service attidue to our business
2. Pofessional advise
3. Quick PI confimation
4. Close production follow up and production process feedback
5. Safe package
6. Get feekback from your side when items arrived,
7. 12 months warranty for items
Q: What kind of inspection you can provide?
A: JWELL has multiple tests from material purchasing to finished products by different departments, like QA, QC, sales representatives, to guarantee all foldable monitor are in perfect condition before shipment. We also accept the inspection by the third party you appointed.
Q: What is your guarantee period?
A: JWELL provides 12 months' quality guarantee for foldable monitor from your purchase date, except the human damaged and force majeure factor. For a better maintenance, be sure that foldable monitor are using under normal circumstances (not more than 16 hours daily). Beyond the guarantee period machine, JWELL will provide maintenance service and technical support (Hardware and other possible charges, JWELL will not bear the responsibility)
Q: How can I pay for the order?
A: Our payment terms: T/T, Western Union, Paypal, Escrow, Credit card
1) For sample order: 100% T/T or Western Union in advance, Paypal or Escrow is also acceptable.
2) For bulk order: 30%deposit T/T in advance, balance clear before pick up or shipment.
No matter big or small order, just write down details you need Click below "send"
