Home > Products > Rubber Cable > H07RN-F rubber flexible cable electrical VDE with ERP insulation
H07RN-F rubber flexible cable electrical VDE with ERP insulation
- 100000 Meter / Meters per Month
- Qingdao China Rubber Cable
- T/T L/C D/P D/A Credit Card
You May Like
-
5*0.75mm muti-core heat resisting silicone rubber cable
Supplier's Choice
-
H07RN-F Heavy Duty Rubber Sheathed Cable
-
CCC YC YCW rubber cable EPR CPE 450/750V
-
YQ YQW CCC IEC certified 300/500V rubber cable EPR CPE
-
copper core rubber flexible mine cable made in china
-
China Hot-selling 450/750V YC Trailing Rubber Cable
Product Details
| Type | Other, Rubber Cable | Model Number | YC YCW Rubber Cable | |
| Conductor Material | Other, Tinned copper or bare copper Rubber Cable | Insulation Material | Other, EPR Rubber Cable | |
| Place of Origin | Henan, China | Brand Name | SANHENG Rubber Cable |
Product Description
H07RN-F rubber flexible cable electrical VDE with ERP insulation
| Brand Name | SANHENG |
| Model Number | 3*1.5 3*2.5 3*6 4*1.5 4*2.5 ...... |
| Model Name | Rubber Insulated Cable for Mining Use |
| Manufacturing Standard | JH/T 8735.2 |
| Core Material | Copper |
| Core Number | Mulite |
| Insulation | Rubber |
| Screen | No |
| Sheath | Rubber |
| Rated Voltage | 0.6/1KV |
| Max. Rated Operating Temperature of Conductor | 90℃ |
| Max. Overtaxing Temperature | 130℃ |
| Max. Short-circuit Temperature(within 5 secs) | Lower than 250℃ |
| Laying Temperature | Over 0℃ ; The cable should be heathed beforehand under 0℃ when laid |
| Bending Diameter | Permissible bending radius for multicores is 15(D+d) ± 5%; D is the actual outer diameter of cable; d is the actual outer diameter of conductor. |
| Breaking Strength(Cu core cable) | 7*S(N); S is the total crossection area of cable. |
| Shipping Way | Shipping or as customer required |
| Packing | Wooden drum or Steel drum |
| Payment Item | T/T |
Reference Standard:
-VDE 0282
Application range:
-Hard-hold and power supply device acc
-Day and damp interiors, as well as for limited outdoor use acc
-Light and sound technology
Product feathers:
-Cable working temperature should not exceed +65°C
-Cable have a certain extent of temperature resistance and oil resistance, fit to work outside and working in the smeary enrivonment
Package:
1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement
2) Outer packing: wooden case, carton box
3) Other packing requirement according to client's request
Established in 2000, Henan San Heng Industrial Co., Ltd. with those years' unremitting efforts and endeavors, has achieved sound cooperation and widely compliments from the clients throughout our country and all over the world by superior quality, reasonable price and sincere services.
Our products are mainly covering PVC cables .building cables, XLPE insulated power cables, PVC insulated power cables, aerial-bundle cables, PVC insulated wires, control cables, rubber cables, bare conductors, welding cables, and other related products.
Main Markets: Domestic market, Africa, Eastern Europe, Southeast Asia.
Director Mr. Lee together with all staff members sincerely welcome your visit and guidance at anytime!
High quality, factory price, wholesale, customization, wholehearted service, various specification. Welcome inquiries !
Why you choose us?
1) Your inquiry will be replied to within the hour
2) Your label design according to your requirements ready in 2 days
3) 16 years OEM/ODM experience
4) Goods are sold with rerun or refund guarantee due to quality issue!
5) prompt shipment by reputed shipping line and professional documents
6) cargoes photo before and after loading into container after shipment with e-mail
7)15 years after-sale service
If you have any problem , please don't hesitate ro contact us.Your inquiry is welcomed at anytime.
we are confident to render our best service to you with promptness & efficiency.
