copper core rubber flexible mine cable made in china
- 10000 Meter / Meters per Month
- Qingdao port or as yur request of copper core rubber flexible mine cable made in china
- T/T Credit Card PayPal
-
Power Accessories Photovoltaic lines Wires UL10269 high voltage cable
-
Factory Direct House Wiring 2.5mm2 Single Core Flexible Copper Wire Electrical Wire Installation Electric Cables Price
-
XTW CXWT 300V UL62 PVC FIexible Cord
-
Enameled Copper wire
-
3x185mm2 Overhead Insulated Cable
-
Service Drop Cable XLPE/PVC/PE Insulated
Product Details
| Place of Origin: | Henan, China | Brand Name: | San Heng | Model Number: | yc |
| Type: | Insulated | Application: | Other, construction, welding machine | Conductor Material: | Copper |
| Conductor Type: | Other, Stranded / Solid | Insulation Material: | Rubber |
Product Description
copper core rubber flexible mine cable made in china
copper core rubber flexible mine cable made in china
The welding cable can be used in the connectors of electric weld and plier of the electrical welding whose toward earth
1.The welding cable can be produced according to the standard ISO-9001
2.Specific Property for Using
(1) The cable can be used in the connectors of electric weld and pliers of the electrical welding whose toward earth voltage is not more than AC 200V and the pulsed DC peak value is 400V.
(2) The long-time permissible working temperature of cable is not more than 65C
3. Name and IEC Standard
(1) Rubber and sheathed welding cable 245IEC 81
(2) Rubber sheathed welding cable 45IEC82, which is made of the composite materials.
(3) Model Names and work in the temperature
Model | Name | Working temperature of core <(C) |
YH | Natural rubber sheath for welding cable | 65 |
specifications and technical data of copper core rubber flexible mine cable made in china
Section (mm²) | Core/No.dia (mm) | Thickness (mm) | OD (mm) | 20 °Cconductor resistance< (Ω/km)
| Reference weight (kg/km) |
10 | 322/0.2 | 0.8 | 7.5-9.7 | 1.91 | 146 |
16 | 513/0.2 | 2.0 | 9.2-11.5 | 1.16 | 218.9 |
25 | 798/0.2 | 2.0 | 10.5-13.0 | 0.758 | 316.6 |
35 | 1121/0.2 | 2.0 | 11.5-14.5 | 0.538 | 426 |
50 | 1596/0.2 | 2.2 | 13.5-17.0 | 0.379 | 592.47 |
70 | 2214/0.2 | 2.4 | 15.0-19.5 | 0.268 | 790 |
95 | 2997/0.2 | 2.6 | 17.0-22.0 | 0.198 | 1066.17 |
120 | 1702/0.3 | 2.8 | 19.0-24.0 | 0.161 | 1348.25 |
150 | 2135/0.3 | 3.0 | 21.0-27.0 | 0.129 | 1678.5 |
185 | 1443/0.4 | 3.2 | 22.0-29.0 | 0.106 | 1983.8 |
arge quantity d first order could enjoy a !
International standard packing: pp bag, woven bag, wooden drum, steel drum, or as per esteemed customers' request.
1.Established in the year 2000. Factory Size: 5,000-10,000 square meters with advanced equipments 7 production lines. 8 engineers 5 R$D elites. 80 production staff workers. 30 sales person.
2.We have more than 20 years manufacturing experience and almost 15 years experience of export.
3.Mian products: PVC cables .building cables, XLPE insulated power cables, PVC insulated power cables, aerial-bundle cables, PVC insulated wires, control cables, rubber cables, bare conductors, welding cables.
4.Main Markets: Africa, South America, Mid East, Eastern Europe, Southeast Asia.
Quality First ! Customer First ! Service First !
We have got China national quality certification CCC and in accordance with Intenational standard IEC. also can customize as your requested standards.
1. Quality assurance
2. Professional production
3. Long service life
4. Customization
5. ISO 9001/CE/RoHS/CCC approved
6. Factory price, because we can make some raw material
7. Short delivery time
8. Factory direct sales, reasonable price
9. 15 years experience.
