Specifications
Hot sales enameled aluminum flat wire from China manufacturerWith 25,000 tons enameled wire output per year.
Standard: IEC,
1.Specifications:
Diameter:0.2mm-8.0mm
Standard: IEC, NEMA,GB
Thermal Class: 130/155/180/220 centigrade
Certification:SGS, UL Approved, ISO9001
2.Features:
a) Excellent resistance to abrasion and solvent,
b) Excellent electricity performance
c) Excellent heat shock, adherence and flexibility,
d) High cut through
3.Main Applications:
a)Small transformers, linear motors, relays, solenoids, small motors, clock coils, watch coils, magnetic heads
b)Automotive sensors and coils as relais and ignition coils
c)Generators,dry-type or oil-immersed
d)Anti-explosion motor,air-conditioner compressor,washing machine
e)Military and space applications
Lead time/Packing
Lead time: within 15 days for each 20' container after received the advanced payment
Packing: wooden box or cartons as your requirements.
MOQ: 1 ton
Delivery port: Shanghai or Ningbo
Details Tech Information of enameled aluminum wire 8 gauge :
Name |
enameled aluminum wire 8 gauge | ||
Type |
QZXYL-2/180 |
||
Diameter |
2.40mm |
||
Standard |
IEC60317-15 |
||
Test Item |
Unit |
Technical Requirement |
Test Result |
Appearance |
|
bright and clean, Uniform color, |
Ok |
Overall Diameter |
mm |
<2.518 |
2.483 |
Conductor Diameter |
mm |
±0.024 |
2.402 |
Thickness of insulation film |
mm |
>0.079 |
0.081 |
resistance |
Ω/m |
<0.006354 |
0.006069 |
Elongation |
|
>15% |
27% |
winding test |
|
no cracking |
Ok |
Tensile Test |
|
15% No cracking |
no cracking |
Peel twist |
|
insulation film Without losing adhesion |
Ok |
Jerk test |
|
insulation film Without losing adhesion |
Ok |
Resistance to heat shock |
C |
200C insulation film no cracking |
Tensing 15% half an hour, no cracking |
Resistance to solvent |
|
Standard solvent “H” Pencil |
2H is ok |
Breakdown Voltage |
KV |
5.0KV |
14.8,14.8,14.9,14.2,14.8 |
package |
|
Meet the export standards |
Ok |
Quality Control Result |
|
Ok |
|
4.Applications of enameled aluminum wire 8 gauge
a)Small transformers, linear motors, relays, solenoids, small motors, clock coils, watch coils, magnetic heads, instruments,speakers.
b)Automotive sensors and coils as relais and ignition coils.
c)Generators,dry-type or oil-immersed.
d)Anti-explosion motor,air-conditioner compressor,washing machine
e)Military and space applications.
Thanks for your attention !!!
