Professional furniture water curtain spray booth for metal pieces
- 100 Unit / Units per Month
- shanghai
- T/T Credit Card
- spray booth car painting for car body repair equipment VPB-E800
- Vico CE Approved Car Spray Booth Paint Booth Baking Booth #VPB-E800
- Vico Hot selling Car Spray Booth Factory Price Car Spray Paint Booth Automotive Paint Box #VPB-E700
- Vico hot sale CE Certificate auto electric spray booth car painting booth VPB-E600
- CE Approved Vico Auto Spray Booth Car Painting/Spray car painting booth on hot sale VPB-SD58
- CE Approved Auto Paint Room Automotive Vehicle Spray Booth Car Body Painting Machine VPB-SD68
Product Details
Power: | 20-315 kw | External Size: | cm | Internal Size: | cm |
Voltage: | 220V to 1140V | Certification: | CCC | Disc Dia.: | cm |
Place of Origin: | Jiangsu, China | Brand Name: | jsours | Model Number: | water wash spray booth |
Product Description
water spray
Water Wash Paint Booth
Air is drawn through a continuous curtain of moving water, and suspended paint particles are scrubbed out.
When air changes direction, centrifugal force slings the solid particles out of the air stream.
Entrained paint particles are thrown against adjacent walls and curtains.
Water flushes the particulate into the collection pan.
Air reaching the exhaust stack is free of airborne particles, keeping the stack area cleaner longer.
Water Rotary Paint Booth
No pump water rotary spray booth avoids blockage in water circulation systems.
Outdoor air is filtered at the top of the spray chamber and then goes into the spray booth. Top-down flows around the workpiece and operating workers will exhaust air containing particulate matter quickly to water-rotator under the floor grilles because the role of outdoor ventilation exhaust fan. The overflow is atomized under the action of high-speed air and then be mixed with air stream inside the rotator. Particles will be washed into the water, after swept through the channel and static pressure chamber by air, the separated water flows back automatically to overflow plate, purified air is discharged outside the high-altitude exhaust fan. This back and forth cycle can effectively remove all the particles in the air.
Contact us to customize Water Spray Booths available in any sizes.
booth|water curtain spray booth|spray booth water curtain|water paint spray booth|water based paint spray booth|water based spray booth
Mainly technical parameters: | |||
Item | Unit | Item | Unit |
Production capacity | 6000 pcs/8-hr | Fuel | 20~30 L/h |
Width of belt conveyor | 1450 mm | Air compressor | 2800 L/H |
Height of working | 750 mm | Power | 15 kw |
Paint type | oil or water | Weight | 12 t |
