Specifications
1.Environmental protection and energy saving;2.Safety;
3.Easy operation;
4.etc..
Introduction
MSR Devulcanizer adds the softener to waste vulcanized rubber powder and activation, at atmospheric pressure under the condition of high temperature, makes the part of the S = C, S = S disconnected to achieve the purpose of the plasticization. Main components: the main heating system, automatic control system, cooling system and batching system,etc.
Tire Rubber Powder manufacturing Process
Characteristic
1. Environmental protection and energy saving: no waste water, waste gas, using circulating water cooling. Plasticizing powder
consumption per ton of 100-170KW;
2. Safety: atmospheric pressure conditions of production, the operator feeding on the ground;
3. Easy operation: PLC control, man-machine interface operation;
4. Each module has a real-time measurement value of feeding, discharging, water temperature into the PLC control system;
5. Each module individually sets temperature, temperature error within ± 1 °C;
6.Using electromagnetic heating or heat conduction oil furnace in two ways;
7.Products do not stick on conveyer, no need to clean up, with production while cleaning function;
8.Process parameters of memory function, memory function formula, etc;
9.Easy installation and maintenance, safe and reliable and remote maintenance.
Technical Data
| Model | MS R10 | MS R15 | MS R20 | ||||
| Production Capacity(T/24H) | 7~12 | 10~16 | 14-22 | ||||
| Heating Method | Electromagnetic/ Heat Conducting Oil | Electromagnetic/ Heat Conducting Oil | Electromagnetic | ||||
| Power(Kw) | 158 | 192 | 296 | ||||
| Operating Temperature(°C) | 200~320 | 200~320 | 200~320 | ||||
| Dimensions(mm) | 9600X6000X5000 | 9600X6000X6000 | 10200X8500X6800 | ||||
| Weight(KG) | 18500 | 24600 | 46500 |
