Help CenterDual Band Selective Repeater Good for Mobile Phone Operator Use Repeater
Related Products
-
Selective Gsm Repeater Cheaper PriceNegotiableMOQ: 1 Piece -
GSM Selective Band Signal Repeater Dcs/wcdma 3g RepeaterNegotiableMOQ: 1 Piece
-
27dbm Output Power 5000sqm Work GSM Selective Band Singal Booster Amplifier KS27C-GSMNegotiableMOQ: 20 Pieces
-
850 Coverage 5000sqm Work Outpower 27dbm Gain 70db Special Selective Band CDMA Signal Amplifier KS27C-CDMANegotiableMOQ: 20 Pieces
-
Lintratek Brand 3G WCDMA 2100 10 Dbm Selective Band Repeater Supplier in China Signal Booster Mobile Network SolutionNegotiableMOQ: 5 Pieces
Specifications
selective band repeater with CE,ISO1. Cover 2000 m2.
2.selective band.
3.AGC and MGC function.
dual band selective repeater good for mobile phone operator use repeater
Why do you need to buy repeater/booster?
Cell phone becomes especially helpful when people get into critical situations. In case of emergency a timely call can save somebody’s life.
Unfortunately, there are still some places where they can find themselves “out of coverage” ,no signal at all... Usually those places are either too far from the cell phone base station or located inside underground constructions, for example:
- Parking lots, tunnels
- Big stores, office buildings
- Cars, boats etc.
- House in remote areas
How can repeater bring your mobile phone better signal?
•The outside antenna catches low signal from operator servicer’s base station and delivers it to cell phone repeater through the connection cable (coax).
•After the signal is accepted by the mobile repeater, this device amplifies it.
•Then this amplified signal goes through the connection cable (coax) to the inside antenna.
•And after that, the amplified signal transmits to your cell phone.
• Finally, your cell phone will get good signal, never on and off
A regular cell phone repeater consists of: (full kit)
— Outdoor antenna , log periodic antenna ,wall mounted antenna, yagi antenna .
— Indoor Omni ceiling antenna , panel antenna .
— Power adapter .
— User manual .
— Cell phone repeater .
— 10 meters outdoor cable .
Specification should care about :
Model No |
KS20E-GD |
||
Parameter data |
Uplink |
Downlink |
|
Frequency Range |
UL:890-915mhz UL:1710-1785mhz |
DL:935-960mhz DL:1805-1880mhz |
|
Output Power |
15 ±2dBm |
17 ±2dBm |
|
Gain |
70 dB |
70 dB |
|
Bandwidth |
Wide Band |
||
Automatic Gain Control |
>20dB |
||
Ripple in Band |
≤5dB |
||
Intermodulation Products |
9KHz~1GHz |
≤ -36 dBm |
|
1GHz~12.75GHz |
≤ -30 dBm |
||
Spurious Emission |
9KHz~1GHz |
≤ -36 dBm |
|
1GHz~12.75GHz |
≤ -30 dBm |
||
Noise Figure @ max. gain |
≤ 6 dB |
||
VSWR |
≤3 |
||
MTBF |
>50000 hours |
||
Power Supply |
AC:90~265V, 50/ 60Hz;DC:12V 3A |
||
Power Consumption |
< 20W |
||
Impedance |
50 ohm |
||
Mechanical Specification | |||
RF Connector |
N-Female |
||
Cooling |
Heatsink Convection cooling |
||
Dimensions (D x W xH ) |
250*330*53mm |
||
Weight |
2.5Kg |
||
Installation Type |
Wall Installation |
||
Environment Conditions |
IP40 |
||
Humidity |
< 90% |
||
Operating Temperature |
-10°C ~ 55°C |
||
