Specifications
4G Selective band repeater1)Coverage:1200~1500sqm
2)Output Power:20dbm(Auto-shut)
3)Gain:70dB(AGC)
4)certificate:CE&RoHs
4G LTE band selective repeater
Specification:
Frequency range:
uplink: 2500~2570mhz downlink: 2620~2690mhz
Model No.: KS20E-LTE-26
1. Output from 15dbm to 20dbm
2.Gain from 65 to 75db
3.Works on 4G LTE system
4.Maintain safe and specific output signal levels and give alarms on self oscillation .
5. Ideal for house ,home ,office use
6. Built in AGC and AlC circuits, which can automatically control the gain of the repeater depending upon the strength of input signals.
7. Compact size, low consumption, easy installation, cover about 1200-1500 m2, high linear design, low interference to BTS.
8. Multiple phones and other handheld devices throughout a building can benefit from a wireless repeater.
9. Extended phone battery lifespan.
10.ALC Function
11.Improve you mobile signal, no more dropping calls,no more bad network speed.
12.Application: expand signal coverage where signal is weak or available,eg.basement,high building,underground,countryside ect.
Parameter Sheet:
| Working System | 4g LTE selective band |
| Gain | 70dB |
| Output Power | Uplink:15 dBm Downlink:20dBm |
| Ripple in Band | ≤3dB |
| Weight | < 2.5 Kg |
| Dimensions | 250x165x53 mm |
| Power Supply | AC:90~265V, 50/60Hz,DC:9V 5A |
| Power Comsumption | < 25W |
| RF Connector | N Female |
| Environment Conditions | IP40 |
| Installation Type | Wall |
| Operating temperature | -10°C-55°C |
| 20dbm for commercial use |
Products Details pictures:
How to work :
1.Outdoor antenna (normall use yagi/log-periodic antenna)receives signal from signal tower.
2.Then sends signal to repeater through cable .
3.Repeater accepts and improves the signal .
4.After that,the fine signal goes into indoor antenna(panel/ceiling antenna) ,via cable to your mobile phone.
Note : The product is not including cable,outdoor antenna,indoor antenna,you need to buy extra.
