Trade assurance brilliant quality clamshell packaging machine
- 5 Set / Sets per Month
- SHENZHEN
- Huitai hot selling OEM auto hot plate sheet board plastic pallet welding machine
- Auto Plastic Pallet sheet plate board Hot Plate Welding Machine for pallet
- automatic PP board edge sealing machine, coroplast sheet layer pads welding machine
- Huitai plastic capillary tube welding machine plastic welders pvc plastic hot plate welding machine bonding
- PP Membrane Hot Filter Plate Chamber Filter Press Plate and Frame Filter Plate welding machine
- Plastic PP Membrane Hot Chamber Filter Press vertical Frame Filter Plate welding machine plate-and-frame belt
Product Details
Place of Origin: | Guangdong, China | Brand Name: | QO | Model Number: | QO-8KWDZT |
Voltage: | 220V 50/60HZ | Power: | 8KW | Frequency: | 27.12MHZ |
Welding Area: | 110cm2 | Dimensions: | 1600*1200*1860mm | Weight: | 350-1500KG |
Usage: | blister packing | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Trade assurance brilliant quality clamshell packaging machine
QO-**KWDZT:
An automatic sliding desktop high frequency synchronous fusing machine Product description:
High with wave synchronous fusing machine can be called: High Frequency Fuse, synchronous fusing machine, high frequency welding machines, high frequency plastics welding machines, welding cutting machines, high frequency, high frequency machine ... etc because it is at the same time to complete, so called high frequency synchronization. . Fuse advantage of this machine is: the material can be welded while welding, or welding material quickly cut off the excess solder within seconds after the effect of the product makes the process more perfect this machine is mainly used for high frequency welding at the same time need to be synchronized cutting works product processing, high frequency machine is the use of high frequency welding and then through the first machine with some pressure device and cut off.
Second, the automatic sliding desktop high frequency synchronous fusing machine Product Features:
High-cycle circuit optimization design, using digital type anti-jamming circuit.
For APET, PETG good effect fusible material.
5557 high sensitivity spark protection system to prevent damage to the mold.
Cardboard and plastic welding and cutting at the same time, while completing two processes.
Using Chinese-made high-quality (optional in Japan Toshiba original) oscillating tube, stable and reliable performance and long life.
Third, automatic sliding desktop high frequency synchronous fusing machine Product Features:
While welding and cutting all kinds of car accessories.
While welding and cutting discs, CD discs bags.
While welding and cutting a variety of costumes, trademark, straps, belts and other products.
Particularly suitable fusion PET (G) of environmentally friendly materials.
While welding and cutting synthetic leather products.
While welding and cutting cardboard and plastic.
Fourth, automatic sliding desktop high frequency synchronous fusing machine Scope:
Mainly applicable to APET, PETG, GAG environmentally friendly materials double-sided blister sealing packaging, blister card packaging paper, toothbrush sealed packaging, as well as EVA leather cloth, leather, OPP, PU, straps, lanyards, water bottle, thermal bags, food, cosmetic, pharmaceutical, tobacco, clothing, chemicals, textiles, gifts, arts and crafts, toys, hardware, machinery, precision Footwear, trademarks, purses, handbags, stationery, signs, etc .. need welding To synchronize blown products.
Five automatic sliding desktop high frequency synchronous fusing machine technical parameters:
Model | QO-5KWDZT | QO-8KWDZT | QO-12KWDZT | QO-15KWDZT | QO-25KWDZT |
Output Power of Generator | 5000W | 8000W | 10000W | 15000W | 25000W |
Anti-Spark System | NL-5557 High sensitive anti-spark system(Optional) | ||||
Voltage | 3P AC 380V/220V 50Hz-60HZ or customize | ||||
Frequency | 27.12MHz +/- 0,6 % | 13.56MHz +/- 0,6 % | |||
Input power | 8KVA | 15KVA | 20KVA | 25KVA | 35KVA |
Rectifier | SILICON DIODE |
| |||
Oscillation tube | 7T85RB | 7T69RB | E3130 | 8T85RB | 8T25RA |
Max pressure | 350KGS | 500kg | 800kg | 1000kg | 1500kg |
Operation mode | Manual or motorized | ||||
Max gap of electrodes | 200mm | ||||
Activities size | 100mm | ||||
Upper Electrode (L*W) | 350*200mm | 500*300mm | 600*400mm | 700*500mm | 800*600mm |
Size of Work Table (L*W) | 450*300mm | 600*400mm | 700*500mm | 800*600mm | 900*700mm |
Welding time | 0.01~9.99s adjustable | ||||
Net weight | 5-10T | 10-15T | 15-20T | 20-25T | 25-30T |
Welcome to buy QIAO automatic sliding desktop high frequency synchronous fusing machine, a variety of equipment can also be customized according to customer requirements! Because improvement needs, specifications and price without notice!
Welcome to buy QIAO Austrian high frequency advertising cloth stitching machine, all kinds of equipment can also be customized according to customer requirements! Because improvement needs, specifications and price without notice! Welcome tent cloth hanging high frequency welding machine, all kinds of equipment can also be customized according to customer requirements! Because improvement needs, specifications and price without notice!Welcome to buyQIAO manual push reel high frequency synchronous fusing machine, a variety of equipment can also be customized according to customer requirements! Because improvement needs, specifications and price without notice!
