PET Semi-automatic Bottle Making Machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L)

PET Semi-automatic Bottle Making Machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L) thumbnail-1
PET Semi-automatic Bottle Making Machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L) photo-1
US$ 11,000 - 80,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Bottle
Plastic Processed:
PET
Contact Supplier Request Quote Chat Now
Zhangjiagang Winmark Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Bottle
Plastic Processed PET
Blow Moulding Type Stretch Blow Moulding
Automatic Yes
Place of Origin Zhejiang, China
Brand Name winmark
Model Number WM-L
Voltage 110-415
Power(W) subject to model
Dimension(L*W*H) subject to model
Weight subject to model
Certification CE ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

bottle making machine
1.modle: JG3L-2C
2.use: to blow PET bottles
3.capacity: 2000 bottle / hr base on 500ml

  PET semi-automatic bottle making machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L)



Machine Features:



  1. Adopt the new type double bend arm and four pull rod-clamping structure (won the patent). Cross direction; middle mould board is move parallel; the distance between two mold bases is adjusted by the chain wheel. Thus, the clamping force is very strong.
  2. The machine frame is produced by the whole complete casting bottom, so that the machine is firm and running stable.
  3. Adopt the straight slide way, reduce the friction and lengthen the life of the machine.
  4. Double start working button, which is designed for avoiding the injury.
  5. Power saving design that can increase your profits.
  6. The single direction of pre-form placing and bottle picking, which increase the output.
  7. Segregate type air controlling system, which is designed for avoiding waste pollution.
  8. The stretching air cylinder is adjusted parallel from front to back, from left to right freely by regulator.







Machine Components:



  1. MOHE air cylinder which produced by China and Japan joint venture
  2. France SCHNEIDER frequency inverter
  3. PID digital power adjuster
  4. Germany SIEMENS touch screen and PLC controller
  5. Swiss PARKER high-pressure blowing valve
  6. Germany BOSCH two position five ways motion valve
  7. Japan OMRON safety sensor











Machine Parameters:







Items

JG3L-2C

Theoretical output

2000pcs/hr

Heating capacity

15kw

Max. bottle volume

2L(2cavity)

Blowing pressure

≤3.5Mpa

Motion pressure

≤1.0Mpa

Max. diameter × height

Φ140×H340mm

Mould thickness

120-220mm

Weight

1500kg

Main machine dimension

1400×600×1600mm×2

Heater dimension

2000×650×1450mm







PET semi-automatic bottle making machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L)



 PET semi-automatic bottle making machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L)PET semi-automatic bottle making machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L)PET semi-automatic bottle making machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L)



Adopting double carnk connecting bar clamping and clamping mould is stable and fast

Adopt for infra-red rotary oven and heated equally.PET bottle blowing machine

1.The air system has been divided into two parts , pneumatic action part and bottle blow part to meet the different requirements for the pressure of action and blow , it can provide sufficient and steady high pressure for blowing large irregular shaped bottles

2.The machine is also equipped with muffler and different parts of refueling system

3.The machine can be operated in step by step mode and the semi-auto mode

4.The machine is small with low investment ,it is easy and safe to be operated by one person.

PET semi-automatic bottle making machine (330ML, 500ML, 550ML, 600ML, 750ML, 1L, 1.5L, 2L)

  bottle making machine bottle making machine bottle making machine bottle making machine bottle making machine

bottle making machine bottle making machine bottle making machine bottle making machine bottle making machine

bottle making machine bottle making machine bottle making machine bottle making machine bottle making machine

bottle making machine bottle making machine bottle making machine bottle making machine bottle making machine

bottle making machine bottle making machine bottle making machine bottle making machine
