Small Waste Paper Recycling Plant/787 Type Toilet Paper Machine

Small Waste Paper Recycling Plant/787 Type Toilet Paper Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Toilet Tissue
Processing Type:
Other, toilet making machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Toilet Tissue
Processing Type Other, toilet making machine
Place of Origin Henan, China
Brand Name FRD
Model Number 787mm
Voltage 220V/380V
Power(W) 5.5KW
Dimension(L*W*H) According to the model
Weight 3000kg
Certification CE
Warranty One Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

 I. Application of Toilet Paper Machine:
Using all kinds of waste paper as the raw material to make new pulp or using virgin pulp as raw material directly, and then produce best quality toilet or tissue paper, it can also to make napkin papers by further processing. This small model use lowest investment and small land to get fast profit.

II.Main Technical Parameters of 787mm Toilet Paper Machine
1.Paper type: medium and high-grade toilet paper,napkin and tissue paper
2.Raw materials: waste paper, wood pulp or wheat straw
3. Gram weight: 13--30g/ m2
4. Paper width: 787mm
5. Cylinder width: 1100mm
6. Design speed: 100m/min
7. Working speed: 60m/min
8.The rail gauge:1300mm
9.The capacity: 0.8-1T/D
10.Pressure type:pneumatic pressure
11.Drive model: frequency control and substep transmission
12.Machine design: square box, left or right position
13.Hanging pulp type: upside down


III.structure and characteristics of 787mm toilet paper machine:
1. cylinder section:Φ1000mm×1100mm stainless steel cylinder mould 1set, Φ260mm×1100mm couch roll 1set,coated by rubber,rubber shore hardness 38°C±2.
2.dryer section:Φ1250mm×1100mm cast iron alloy dyer can 1 set, Φ300mm×1100mm touch roll 1set,1group scraper knife. rubber shore hardness 90°C±2.Mechanical pressure device.
3.paper cutting section: 787mm slitting machine1set .
4.drive and control section: Alternating current , speed control , section drive

IV. Flow chart of 787mm toilet paper machine

Pulp equipment
