technical parameter:
Raw material: waste paper
Output paper: kraft paper;
Paper weight: 100-250gsm
Width of paper: 3200mm
Cylinder mould width: 3750mm
Capacity:30-35T/D
Rail space: 4300mm
Work speed: 80-150m/min
Drive way: alternating current frequency conversion adjustable speed, section drive
Main structures:
1,Cylinder part: Φ1500mm×3750mm stainless stell cylinder mould 2pcs, Φ1500mm×3750mm couch roll 3 pcs(including round roller 1pcs),coated by rubber, rubber Share hardness is 38°C±2.
2,Squeeze water section: Φ800mm×3750mm natural marble roll 1pcs, Φ750mm×3750mm rubber roll 1 pcs, coated by rubber, rubber Share hardness is 90C±2. Pneumatic pressure device
3,Dryer section: Φ2500mm×3750mm alloy dryer 2pcs, Φ750mm×3750mm roller 1pcs, rubber hardness shore 90 °C±2 ,pneumatic pressure device; 2nd dryer section Φ500mm×3750mm opposite pressurized roll 1 pcs, rubber hardness shore 90 °C±2, 2nd dryer section route mesh device.
4, drive and control section: Model-650 speed reduction 1 set, Model-500 speed reduction 2set, adopt alternating current, frequency conversion, speed control, section drive, closed digital signal control system.
Qinyang City Friends Machinery Equipment Co.,Ltd located in Qinyang City, Henan province, China, is one of leading paper machine manufacture,which specializes in pulp making machine, paper making machine and paper processing machine manufacturing.
Our company has perfect service system. We have engineer team with rich practice experience, who can supply professional service during the whole deal, including technbology consultation, design factory, project evaluation, detailed design of factory, installation and testing the whole production line, training engineers and workers.
