150 ton/day 3200mm Fourdrinier fluting Paper Making Solution
Technical Data of the Kraft Paper Machine
1.Raw material: recycled paper
2.Output paper: fluting paper
3.Output paper weight: 90-150g/m2
4.Net paper width: 3200mm
5.Capacity: 150 tons /day
6.Drive way: A/C inverter speed control, sectional drive
Main equipment structure:
1.Wire part:fourdrinier table covered with stainless steel board, air loaded head
box made of stainless steel.
2.Press part:2 sets of press rolls in large diameter.
3.Dryer part:30 pcs of 1800mm×3750mm×4300mm alloy dryer cylinder
4.Winding part :1 set of 3200m horizontal pneumatic winding machine
Main equipments of the Kraft Paper Machine:
No. |
Item |
Quantity(set) |
1 |
3200mm Fourdrinier fluting paper making machine |
1 |
2 |
Semi-closed dryer hood |
3 |
3 |
Propeller fan |
6 |
4 |
roots vacuum pump |
3 |
5 |
Vacuum suction box |
12 |
6 |
Paper scanning machine |
1 |
7 |
3200mm double-roll calendaring machine |
1 |
8 |
3200mm Horizontal pneumatic winding machine |
1 |
9 |
3200mm Frame type rewinding machine |
1 |
10 |
Frequency conversion controlling cabinet |
1 |
11 |
Air compressor |
3 |
12 |
Air tank |
2 |
13 |
The whole set of working platform |
1 |
14 |
6 T Boiler |
2 |
Qinyang City Friends Machinery Equipment Co.,Ltd located in Qinyang City, Henan province, China, is one of leading paper machine manufacture,which specializes in pulp making machine, paper making machine and paper processing machine manufacturing.
Our company has perfect service system. We have engineer team with rich practice experience, who can supply professional service during the whole deal, including technbology consultation, design factory, project evaluation, detailed design of factory, installation and testing the whole production line, training engineers and workers.
