1575mm Kraft paper making machine from FRD

 The main structure

1. Cylinder section: Φ1250mm×1950mm stainless steel cylinder mould 2 sets, Φ380mm×1950mm couch roll 2 sets, φ380×1950mm reverse roll 1set, coated by rubber, rubber shore hardness 38°C±2.

2. Press section: Φ450mm×1950mm marble roll 1 set, Φ400mm×1950mm rubber roll 1 set, coated by rubber,rubber shore hardness 90℃±2. Pneumatic compression device, allocating a

group of scraper.

3. Dryer section:Φ1500mm×1950mm dryer can 2 set, 450mm×1950mm touch roll 1 set, Φ400mm×1950mm doubledryer cans fly roll 1 set, allocating two scrapers and setting the dried wire

device od double-dryer can. Pneumatic compression device, coated by rubber,rubber shore hardness 90°C±2.

4.Winding part: 1575mm cylinder paper winding machine and paper rewinding machine.

5. Driving and controlling part: using of AC frequency conversion, and driving by step.

Papermaking equipment selection Chinese, Chinese papermaking equipment is the first Qinyang Friends. Qinyang City Friends Machinery Equipment Co., Ltd. is specializing in the production of pulp and paper series of complete set of equipment, set research and development, production and sales as one of the modern enterprise.

Friends machinery with advanced modern management system, Seiko produced, independent innovation, collected and created a large number of technical backbone and management elites, all products were certified by CE, enterprise products continuously updating, with exquisite craft, advanced papermaking technology, strict quality, excellent performance of renowned at home and outside, and in a few years like a day of sincerity has been widely recognized by customers. Products sold throughout the country, exported to Southeast Asia, the Middle East, Russia, Mongolia. Jordan. Indonesia, Bangladesh and other regions.

The company has first-class sales and technical service team, according to customer needs to provide project design, process design and technical training, etc.. A pre-sale, sale, the after-sales tracking service, fully eliminate the worries of the majority of customers.
