tissue paper in toilet tissue for waste recycle paper making machine

Toilet paper process

1.Pulp making line (from waste paper to pulp)

Waste paper---Pulping---Screening---Pulp washing---Defibrination---Rescreen    Size mixing---Mixed pulp---Desander---Go to the paper machine

2.Paper making line (from pulp to tjumbo roll  paper)

Pulp go on the cylinder ---Press ---Drying ---Reeling ---Slitting ---Packing --- Storage

3.paper converting part

jumbo roll paper ---slitting machine--toilet roll cutter---finished tissue paper

Technical Parameter:

1. Output paper : toilet paper;

2. Raw material: virgin pulp ,waste paper;

3.Capacity: 5-6ton per day;

4. net paper width: 1800mm;

5. Output paper grammage: 13-40g/m2;

6.Width of cylinder mould: 2350mm;

7.bearing center-center:2900mm;

8 Drive way: Alternating current ,frequency conversion, speed control, section drive;

Toilet machine list

Raw Material

Pulp flow

1. Fixed all the movable parts with plastic films.

2. Polystyrene foam plate wrapped around.

3. Wrapped with tighted plastic films several circles.

4. Fixed machine on the fumigated plywood pallet with iron wire.

5. Wrapped with wooden board around and nailed on.

How to get your suitable machine and production lines?

1.inquiry:contact us by email,phone,fax,skype,MSN etc.
2.negotiation:after getting our quotation,you confirm the paper machine model and specify the

items you desire.
ntract:place order and signing the agreement files.
duction:as soon as we received first payment,we will start to produce machines.we will notify

client to book the ship 15days in advance.
5.delivery: all the machines will be shipped according to contracted items.

6.installation:we will send engineers/technicians to install the whole production line.

After-sales service

1. Our company view adhering to the "excellent quality, customer satisfaction" service concept,

to provide you with excellent products and perfect service.

2. Our company keep the contract and reputation. Quality first, products guarantee a year, as it is

quality problem, free replacement.

3. For every purchase of our company's products, the company can send technicians to guide the

installation and debugging, and can undertake the design of process and equipment installation.

4. Our company ensure that supply of parts discount all the year around

Henan Qinyang Friends machinery manufacturing co.,ltd has developed into a much more competitive company since establishment in 1983.mainly manufactures all kinds of paper machines,toilet paper production line,kraft paper

production line,copy/writing paper production line.We have 4 paper machine producing workshops and more than

110 workers.our factory total area is 20,000 square meters.

Our company superiority: 1.more than 30 years producing experience. 2.alibaba1year of gold supplier. 3.25 engineers with rich experience. 4.have passed CE,SGS,ISO quality system certification and all manufacure processes are conducted by the standard strictly.

Technical support: 1.Free consulting services, help the user to do project feasibility analysis.2.Series of products related information for customer reference. 3.According to customer's actual situation, to provide equipment design and installation drawings and production of the required information. 4.Production of various materials used for grades, technical performance indicators, requirements, suppliers, and reference price and related information. 5.Common faults and trouble shooting in the use of production. 6.Can send technicians to install test equipment and design.

you maybe pay more attention to the follow point

1. buying guide

What kind of paper you want to produce?

How many tons do you want to produce per day ?(24 hours)

What kind of raw materials you use to make paper pulp?

(waste paper,old carton box,wood,wheat straw,rice stalk,wood chips,reed,bagasse, cotton,bamboo and so on )

 What's the output paper weight (thickness)you require?(mm)

What's the output paper  width of jumbo roll you require? (mm)

waht kind of finished paper you want ?

2 Why we choose your company, what could you do for me?

We have the stable production experience.

We use the best steel to guarantee the products’ quality

Warranty:we make our machines one year warranty.

We will always give you heart to heart service

We always speak with facts and quality

3. How we visit your factory and what will be the procedure?
Our company located in JIAOZUO city,Henan province, if you take plane, it needs about 2 hours from Guangzhou city, 1.5hours from shanghai city and 1 hour from Beijing.we will pick you up from airport as

well as the train station. We will take you to see our working paper  machine line .Welcome you and your team to visit us at any time!

4. Could your engineer teach and train our worker and stay in our factory for long time?
Yes, we have very large engineer installation team,they can train and teach your worker to operate paper machine,but you should pay them salary.

 5. Which kind of chemical be used in pulp line

(1) Deinking agent

(2) Dispersing agent

(3) Bleaching agent

 6. How about your company orders?

(1)One set of paper machine line or part is supported by us
