XPG-900 32-34 FANS Rubber Film Cooler

Name: XPG-900 32-34 FANS Rubber Film Cooler
Brand: CN HUATUO
SKU: 109306369
Availability: InStock

US$ 2,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, film cooling line

Place of Origin:

Shandong, China

Qingdao Huatuo Mechanical Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, film cooling line

Place of Origin Shandong, China

Brand Name CN HUATUO

Model Number XPG-600-700

Voltage 380V or different

Power(W) 13KW

Dimension(L*W*H) 11*2*3.3m

Weight 7000kgs

Certification CE and ISO

Warranty two years

After-sales Service Provided Engineers available to service machinery overseas

Rubber sheet Cooling Machine Batch-off Cooler With factory price

Usage

1. Rubber cooling machine is mainly use to cool all size of rubber sheet.

2. Automatic PLC system

Working condition

1. Machine application:The rubber sheet from the Calendar or Twin Screw Extruding

Sheeter, soaked, cooled, dryed etc.

2.Machine using condition:highest temperature 40°C, lowest temperature 5°C, highest relative humidity 95%.

Technical Parameters

Model Series			XPG-600	XPG-800	XPG-900
Max. rubber sheet width		mm	600	800	900
The thickness of the rubber sheet		mm	4-10	4-10	6-12
Rubber sheeting temperature over room temperature after cooling		°C	Room temperature + 5 degrees Celsius	Room temperature + 5 degrees Celsius	Room temperature + 5 degrees Celsius
Linear speed of taking-in conveyer		m/min	3-35	3-35	4-40
Linear speed of sheet hanging bar		m/min	1-1.5	1-1.5	1-1.5
Hanging height of the sheet hanging bar		m	1.3	1000-1300	1.3
Number of cooling fans		Set	According to customers	20-32	32-34
Total power		kW	7	7-11	7-11
Length	L	mm	14250	16800	26630-35000
	W	mm	3300	3400	3500
	H	mm	3405	3520	5630
Gross weight		t	4.5	6	6
