GP125 0.125KW China Water Pump Price

Specifications

GP125 0.125KW China Water Pump Price

Application

This series pumps are with peripheral impeller containing numerous radial blades in its edge. Self-priming because the particular design of the pump body ensures the elimination of any air in the suction piping. The re-circulation of the pumped fluid induced by the particular shape of the pump body permits the self-priming effect, extracting and completely expelling any air in the suction piping. The fluid pressure increases progressively as it passes from the suction opening to the delivery opening, ensuring an even, non-pulsing flow and high pressure with particularly steep curves.

Operating conditions
Liquid temperature up to 60
Ambient temper up to 40
Total suction lift to 9m
Continuous duty

Construct

Pump
Pump body: Cast Iron
Impeller: Brass
Motor: Closed, externally ventilated
Insulation class: B and F

Motor
Protection class: IP44 or IP54
Mechanical seal: Stainless steel/Carbon-ceramic
Shaft: 45# Steel / Stainless steel
Thermal protector (if required)

Main Market

Southeast Asia, Middle East, Africa, Europe, America, etc.

Our Enterprise Spirit

The Market is the Core and The Quality is the Life.
We welcome worldwide merchants to join us for common development !

FAQ

Q: What is your MOQ of this item?

A: Our MOQ is a full 20ft container, but for the first time cooperation, we accept samples order to check quality.

Q: Is it all right to make customers’own brand name?

A: Sure, we can be your OEM manufacturer with your authorization of brand.

Q: What are your payment terms?

A: 30% T/T deposit, 70% balance before shipment or L/C at sight.

Q: How long is your warranty?

A: One year after receive B/L.

Q: What is the delivery time?

A: 25-30 days after receiving your L/C or T/T deposit.
