Help Center200kva Diesel Generator Set With Engine 6CTAA8.3-G2
Related Products
-
16kw-1200kw Silent Type ce Certified Diesel GeneratorUS$ 22,800 - 187,600MOQ: 1 Set -
25kva Silent Power Generator With Lovol Diesel Engine Quality ChoiceUS$ 5,000 - 10,000MOQ: 1 Set
-
10kw Silent Power Generator SetUS$ 5,200 - 10,000MOQ: 1 Set
-
10kva Silent Diesel Generator With ATSUS$ 4,300 - 10,000MOQ: 1 Set
-
10kva Diesel Generator Set With Marathon Alternator PriceUS$ 4,171 - 6,600MOQ: 1 Set
Feature :
More power range
Global service and mataince
Between the same power ,the smallest size,between the same size, the lowest noise.
Generator set specification of 200kva diesel generator set with engine 6CTAA8.3-G2:
Technical Specifications | |
Genset model |
SC160GFS |
Genset rated power |
160KW/200KVA |
Rated voltage |
230/400V (adjustable) |
Rated current |
288 |
Frequency |
50 Hz |
Power factor |
0.8 Lagging |
Connecting type |
3 phase 4 wire |
Cooling system |
Closed cycle water-cooled with fan, water tank |
Overall dimension (L×W×H) mm |
2500×960×1590 |
Gross weight (kg) |
1300 |
Diesel Engine | |
Brand |
Cummins |
Model |
6CTAA8.3-G2 |
Engine type |
6 cylinders in line,4 stroke, air-air after-cooled |
Aspiration |
Turbocharged |
Rotating speed |
1500 RPM |
Engine cooling system |
Water-cooled |
Speed governing system |
Electronic speed governor |
Starting method |
By 24V batteries |
Engine filter system |
Dry type air filter ,fuel filter, oil filter, water filter |
Displacement(L) |
7.01 |
Bore×Stroke(mm) |
105×135 |
Compression ratio |
16: 1 |
Lube capacity(L) |
16.5 |
Rated fuel consumption L/h |
39.5 |
Alternator | |
Brand |
Xingnuo |
Model |
XN274H |
Excite type |
Brushless self-excited AVR regulation |
Connecting type |
3 phase 4 pole |
Steady voltage |
≤±1% |
Insulation class |
Class H |
Protection grade |
IP23 |
The components of the genset | |
(1) Diesel engine; (2) Alternator; (3) Water tank & radiator assembly; (4) Control panel; (5) Base frame. | |
1. we supply spare parts during the whole service life.
2. one year warranty. and we are manufacturer with 2 factories in weifang city, after-sale service guaranteed.
3. open frame type/ silent type/ weatherproof type/ trailer/ container type, at your option.
4. Engine brand can be Cummins, Deutz, Lovol, Ricardo
5. Decades’ years of manufacturing and exporting experience
6. Adopt International quality standards, to meet high quality requirement
7. Good reputation for Reliable quality & Reasonable price
8. Strong technical support
9. Advanced production line with skilled workers
