11kva-343.75kva stanby power weifang engine diesel generator for military :
Prime Power(kw/kva):8kw/10kva -250kw-312.5kva
Standby Power(kw/kva):8.8kw/11kva-275kw-343.75kva
Photos of 11kva-343.75kva stanby power weifang engine diesel generator for military
This series diesel gneerator set is powered by Ricardo series diesel engine .With the importing of technology of Ricardo Company (U.K.).The engine has the feature of low fuel consumption ,good power performance ,safety and good reliability .This series generaotr set is widely used as prime or standby power supply in fieldwork ,building ,supermarket ,industrial and mining factory ,oil field, highway ,harbour countryside and so on .
Control Panel of 11kva-343.75kva stanby power weifang engine diesel generator for military
|
Automatic Control Panel is the basic configuration for nobody on duty controlling generator. This kind of panel can accept the remote Start/Stop signals. (Controlled by ATS) Features: adopted Chinese producing, Auto control system, with large LCD,Display in English (or CHINESE) to show the menu. With Auto Control Panel .generator are of various functions such as auto/manual stop (Emergency Stop), programmable plugs for input and output detected data, symbols diagram will show in the LCD, etc. |
Standard Control Panel is the basic configuration for normal operation and usage. It is of some advantage such as easy to operate various function and well protection. Operative buttons such as Turn On, Per-heart. Starting, Stop (Emergency Stop) on the panel .while malfunction occurs, control panel will stop the generator and also alarm with light or buzz.
Specification of 11kva-343.75kva stanby power weifang engine diesel generator for military
| Genset Model | Prime power kw/kva | Standby power kw/kva | Engine Model | Rated power kw | Intake type | No.of Cylinder | BorexStroke mm | Dispalcement L | Lub oil capacity L | Rated fuel consumption L/h | Model alternator | Excitation type | Insulation class |
| SH8GF | 8/10 | 8.8/11 | YSAD380D | 10.3 | Natural | 3 | 80x90 | 1.375 | 6 | 2.88 | WHI164B | Brushless | H |
| SH10GF | 10/12.5 | 11/13.75 | YD480D | 14 | Natural | 4 | 80x90 | 1.809 | 6 | 3.95 | XN164C | Brushless | H |
| SH12GF | 12/15 | 13.2/16.5 | YD480D | 14 | Natural | 4 | 80x90 | 1.809 | 6 | 3.95 | XN164D | Brushless | H |
| SH20GF | 20/25 | 22/27.5 | K4100D | 30 | Natural | 4 | 100x115 | 3.61 | 9 | 7.74 | WHI184FS | Brushless | H |
| SH30GF | 30/37.5 | 33/41.25 | K4100ZD | 42 | Turbocharged | 4 | 100x115 | 3.82 | 9 | 9.45 | WHI184H | Brushless | H |
| SH40GF | 40/50 | 44/55 | K4100ZD | 42 | Turbocharged | 4 | 100x115 | 4.33 | 13 | 14 | WHI224D | Brushless | H |
| SH50GF |
50/62. 5 |
55/68.75 | R4105ZD | 56 | Turbocharged | 4 | 105x125 | 4.33 | 13 | 14 | WHI224E | Brushless | H |
| SH60GF | 60/75 | 66/82.5 | R6105ZD | 84 | Turbocharged | 6 | 105x125 | 6.49 | 16 | 21 | WHI224F | Brushless | H |
| SH80GF | 80/100 | 88/110 | R6105ZD | 84 | Turbocharged | 6 | 105x125 | 6.49 | 16 | 24.53 | WHI274C | Brushless | H |
| SH100GF | 100/125 | 110/137.5 | R6105AZLD | 110 | Turbocharged | 6 | 105x130 | 6.75 | 16 | 27.25 | WHI274DD | Brushless | H |
| SH120GF | 120/150 | 132/165 | R6105IZLD | 132 | Turbocharged | 6 | 105x135 | 7.2 | 18 | 32.25 | WHI274E | Brushless | H |
| SH150GF | 150/187.5 | 165/206.25 | R6113ZLD | 155 | Turbocharged | 6 | 113X125 | 7.52 | 21 | 34.48 | XN274G | Brushless | H |
| SH160GF | 160/200 | 176/220 | R6126ZLD204 | 204 | Turbocharged | 6 | 126X135 | 7.8 | 40 | 54.26 | XN274H | Brushless | H |
| SH200GF | 200/250 | 220/275 | R6126ZLD235 | 235 | Turbocharged | 6 | 126X135 | 7.8 | 40 | 62.2 | XN274K | Brushless | H |
| SH250GF | 250/312.5 | 275/343.75 | R6126ZLD288 | 288 | Turbocharged | 6 | 126X135 | 7.8 | 40 | 75 | XN4ES | Brushless | H |
11kva-343.75kva stanby power weifang engine diesel generator for military Features
1.engine brand:Ricardo .
2.automatic
3.Silent
4.Tairler
5.Stamford generator
configurations
1. Standard High-level quality engine .
2. Standard High-level quality alternator, Stamford, Brushless, 100% copper wires. Protection Grade: IP23, Insulation Class H.
3. Maintenance-free start battery.
4. After acidification under frame, High-level strong.
5. Electric start, use key start.
6. Electric throttle.
7. Standard control panel .
8. Daily fuel tank.
9. High-level shock absorber system.
10. Ripple flexes exhaust pipe, exhaust siphons, flange, Muffler.
11. 40°C radiator as standard.
12. Exhaust silencer
13. Charger motor for battery.
14. Standard export box.
15. Manuals.
16. Tools box.
Our partner
With the high quality and good service we work with these cooperators many years.They have many advantages in everry field.They are your best choice.Cummins,Perkins, Deutz,Yuchai,Weichai,and so on ,their diesel engines are the best quality. Leroy Somer and Malathon superiorer in alternator .
With many year's efforts,We not only the reliable factory ,but also the credit partner
Control Panel
GENERAL SPECIFICATIONS
Ricardo ™ENGINE SPECIFICATIONS
· Ricardo Diesel Engine
· Direct Injected
· Industrial 4-Cycle, Water-Cooled (Radiator-Cooled)
· Engine Speed: 1800 rpm /1500rpm
· Governor: (Automatic) Electrical
· Turbo-charged
· After-cooled (on some models)
ALTERNATOR SPECIFICATIONS
· New Brushless Alternator
· Built-In Automatic Voltage Regulator (A.V.R.)
· Rotating Field, Self-Ventilated, Double-Shielded Single Bearing
· Class [H" Insulation
· Rotor Balance (in accordance with BS5625 Standard 12.5)
Supermaly Shipping
Supermaly Factory
After sales promise:
1. Since gen-set reached the agreed destination, its main parts will be guaranteed
within 12 months or 1500 hours.
2. We give technical guide all the service life. In the warranty days, we send spare
parts for free. After warranty, we take the spare parts cost.
