Specifications
Suitable for use in channels with cover, suitable for fixed protected installation in or on light fittings and inside appliancesWhat are H05VV-F Insulation Cables?
The electrical and physical properties of this cable are rigorously tested by SY Cables Technical and Quality Assurance Department using specialist testing equipment in our in-house cable laboratory. This product is RoHS (Restriction of the use of Hazardous Substances) compliant and conforms to the listed BS (British Standards Institution) Standards. This product conforms to the German VDE product specifications list below which is part of the Electrotechnical DIN standards issued by the DKE (Deutsche Kommission Elektrotechnik Elektronik Informationstechnik). The cable is a Harmonised product and conforms to the European Electrotechnical Standardization (CENELEC) specifications listed and recognised within the European community and further.
Application
For use in household appliances such as washing machines, spin dryers and refrigerators. Generally unsuitable for outdoor use or industrial applications.
0.5 - 2.5mm² to BS6500,
4.0mm² to BS7919
6.0mm² generally to BS7919
VDE28
CENELEC HD21.5
BASEC Approved (2 core to 7 core, 0.75 - 2.50mm² )
Conductor:
Class 5 flexible plain copper conductors, BS EN 60228:2005 (previously BS6360)
Insulation: PVC (Polyvinyl Chloride) to BS7655
Sheath: PVC (Polyvinyl Chloride) to BS7655
Sheath Colour: Black or White
Voltage Rating: 300/500V
Temperature Rating: 0°C to +60°C
Minimum Bending Radius: 6 x overall diameter
Core Identification:
2 Cores: Blue, Brown
3 Cores: Green/Yellow, Blue, Brown
4 Cores: Green/Yellow, Brown, Black, Grey
5 Cores: Green/Yellow, Brown, Black, Grey, Blue
