Specifications
Suitable for use in channels with cover, suitable for fixed protected installation in or on light fittings and inside appliancesWhat are 6491X Insulation Cables?
6491X Insulation cables are wrapped with insulation materials that are lead-free, heat-resistant vinyl (PVC) or halogen free, flame-retardant cross-linked polyolefin over conductors. These cables are used for the cabling of electric devices of less than 450/750 V and for internal power supply.
Application
6491X Cable H07V-R/H07V-U to BS6004 is suitable for power and lighting circuits and building wiring. The cable is intended for use in semi-flush exposed conduits and embedded conduits as well as in closed installation ducts, and is ideal for the internal wiring of appliances and apparatus.
H07V-R: Class 2 stranded plain copper conductors to BS EN 60228:2005 (previously BS6360)
H07V-U: Class 1 solid plain copper conductor to BS EN 60228:2005 (previously BS6360)
Insulation: PVC (Polyvinyl Chloride) Type TI1 to BS7655
Insulation Colour: Red, Black, Blue, Yellow, Brown, White, Green/Yellow, Grey( Note: Insulation colors other than the above may be manufactured on customer request. )
Voltage Rating: 450/750V
Temperature Rating: 0°C to +70°C
The above wiring cables conform to BS 6004 specification for "PVC insulated cables (non-armoured) for electric power and lighting". The cables also generally satisfy the International Specification IEC 60227 (6491 X only) and German standard VDE 0281 for "PVC insulated cables and cords with rated voltage not exceeding 750V"
