Educational Trainer for Wind and Solar Energy Comprehensive Utilization Training

1. Product structure: Desktop module structure.

2. Main parameters:

Size 1700 mm x 700 mm x 1500 mm;

The power supply: single phase AC220V, power < 500 VA.

3. Device composition:

Wind generators, solar panels and solar controller, batteries, Power inverter, dc load, ac load, ac/dc voltmeter, artificial light source, artificial wind source etc.

4. Main functions:

Can complete the wind generator  generation principle, solar photovoltaic  panel energy conversion experiment, the influence of environment on  the wind power generator, influence of environment on photovoltaic conversion experiment , wind-solar complementation controller working principle and protection  measures, away from the nets type inverter working principle experiment and protective measures, ac load and dc load applications, microcontroller programming experiment, the use of single chip microcomputer download software.

5. Annex:

Experimental jump line, commonly used tools, software disc, the product specification.

6. Training Projects

1) the wind generator power generation principle

2) solar photovoltaic board energy conversion experiment

3) and environment on the pv affect the conversion

4) and environment on the influence of the wind power generator

5) and solar battery photovoltaic system directly load characteristics experiments

6) solar controller working principle experiment and protection measures

7) solar controller battery of the overcharge protection experiment

8) solar controller battery discharge protection experiment

9) the distance from the nets type inverter working principle experiment and protection measures

10) ac load and dc load applications

11) microcontroller programming experiment

12) and single-chip microcomputer download software to use

13) IR2110 drive chip applications
