Diesel Generator Welding Machine 190AH
US$ 500 - 580
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BOBIG
Model Number:
BD190WE
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
BOBIG
Model Number
BD190WE
Output Type
Other, AC Single Phase, AC Single Phase
Speed
3000/3600RPM
Frequency
50/60HZ
Rated Power
4KW
Rated Voltage
220,230,240 110/220,115/230,120/240
Rated Current
45-180AH
Specifications
welding1.diesel generator welding machine 190ah
2.diesel generator welding machine 3kw
3.1.2-4.0mm
welding
NEW Italion technology alternator, Reactor regulation
| DC Welder | Rated Current(A) | 170 |
| Rated Voltage(V) | 22-32 | |
| Welding Current Range(A) | 45-190 | |
| Continous working | S1 | |
| Applicable Electrode | 1.2-4.0 | |
| AC Generator | Phase | Single |
| Frequency(Hz) | 50/60 | |
| Rated power(kw0 | 4.0/4.5 | |
| Rated Voltage(V) | 220,230,240 110/220,115/230,120/240 | |
| Power Factor cos | 1 | |
| Engine | Model | BG420F |
| Max.Output(HP) | 15/3600rpm | |
| Displacement(cc) | 420 | |
| Type | Single-cyliner,4-stroke,OHV,Air-cooled | |
| Compression ratio | 8.3:1 | |
| Starting System | Electric | |
| Lubrication System | Air cooled | |
| Cooling system | Non-touch transistorized ignition | |
| Fuel Tank(L0 | 2.5 | |
| Oil Capacity(L) | 1.1 | |
| Sets | Noise Level(at7m) | 72dB |
| Dimension(LWH)mm | 780*590*600 | |
| G.W(kg) | 95 |
The above specificaton is basic structure, optional choices are as follows:
A. Electric starting system
B. Three phase set
C. EPA set and two voltage panel
D. European sockets
E. Smart Panel
F. ATS
We are pleased to quote under your detailed requirements.
