Diesel Welding generatorCurrent:190A,100%Copper wire
AC generator Power:3.0kW/3.3kW
New italy technology alternator
Diesel welding generator
100%COPPER WIRE DIESEL WELDING GENERATOR
Technical Data
Model
BDW190LE
DC Welder
Rated Current (A)
170
Rated Voltage (V)
21-31
Welding Current Range (A)
45-190
Continous working
S1
Duty cycle
190A/20%,170A/60%
Diameter of electrodes
1.2-4.0mm
AC Generator
Phase
Single /Three Phase
Frequency (Hz)
50/60
Rated Output (kw)
3.0/3.3
Rated Voltage (V)
220V,240V(according to your demand)
Power Factor
1.0/0.8
Engine
Model
BD186FA
Max. Output(HP)
9.6/3600rpm
Displacement(cc)
418
Type
Single-cylinder,4-stroke,air-cooled,Vertical
Compression ratio
19:01
Starting System
Recoil/Electric
Lubrication System
Pressure splashed
Cooling System
Air cooled
Fuel Tank (L)
15 diesel
Oil Capacity (L)
1.65
Noise Level(at 7m)
82dB
Dimension(LXWXH)mm
780x590x600
G.W (kg)
120
L:"L"mean:square tube,foot pad,rounded board,2-"8"wheel Accessories for diesel welding generator is Electrode holder,ground clamp,socket,manuals
