Silent Diesel Generator With EPA
US$ 999 - 9,999
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BOBIG
Model Number:
GF-3
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Fujian, China
Brand Name
BOBIG
Model Number
GF-3
Output Type
AC Three Phase
Speed
1500/1800RMP
Frequency
50/60HZ
Rated Power
20KW TO 1000KW
Rated Voltage
230 240 220/127V 400/230V 380/220V
Rated Current
36A-1800A
Specifications
Silent Diesel Generator with EPA1.Brushless alternator
2.Cummins engine
3.65dB(A) @ 7 meters
4.silent or open 20kw to 100
Silent Diesel Generator with EPA
Bobig-cummins series
| Model | GF2-20 | GF2-30 | GF2-40 | GF2-75 | GF2-100 | GF2-150 | GF2-200 | GF2-240 | GF2-280 | |
| ENGINE | Engine Model | 4B3.9-G | 4BT3.9-G | 4BTA3.9-G2 | 6BT5.9G2 | 6BTA5.9G2 | 6CTA8.3G2 | 6LTAA8.9G2 | NTA855-G1A | NTA855-G4 |
| Rated Output(KW) | 24 | 36 | 50 | 86 | 110 | 163 | 220 | 262 | 317 | |
| Max Output(KW) | 27 | 40 | 55 | 93 | 120 | 180 | 240 | 291 | 351 | |
| Governing method | Mechanical/Electric | Electronical | ||||||||
| Intaking method | Natural apirated | Turbocharged | Turbocharged intercooled | |||||||
| Cylinder numbers | 4 | 6 | ||||||||
| Fuel consumption(g/kw.h) | ≤225 | ≤210 | ≤199 | ≤199 | ||||||
| Displacement(L) | 3.92 | 5.88 | 8.3 | 8.9 | 14 | 14 | ||||
| Cooling Starting Method | Closed water cooled/Electric starting | |||||||||
| Crankshaft rotation direction | Counterclockwise(face to output end) | |||||||||
| ALTERNATOR | Model | 184F | 184H | 224D | 274C | 274D | 274H | 274K | C4D | C4E |
| Rated Output(KW)(KVA) | 20(25) | 30(37.5) | 40(50) | 80(100) | 96(120) | 160(200) | 200(250) | 240(300) | 280(350) | |
| Rated Voltage(V) | 400/230V | |||||||||
| Frequency(HZ) | 50/60 | |||||||||
| Power Factor | 0.8 lagging | |||||||||
| Phase/Connection | 3-phase 4-wire Y-type connection | |||||||||
| Excitation | Harmonic or Brushless Excitation | |||||||||
| Voltage Regulation | Automatic/AVR | |||||||||
| Net Weight(kg) | 650 | 700 | 830 | 1390 | 1530 | 1970 | 2300 | 3900 | 4300 | |
| Packing Size LWH(cm) | 180*90*125 | 190*90*133 | 235*92*135 | 238*92*135 | 245*98*150 | 260*98*150 | 325*120*180 | 325*120*180 | ||
Warranty: we offer one year or 1500 hours to our engine and alternator. During these period, w
e provide spare parts for free,but air filter, oil filter or some parts which are easy to consume is not included.
