DUETZ GENERATORS

Name: DUETZ GENERATORS
Brand: BOBIG
SKU: 109129751
Availability: InStock

US$ 999 - 19,999 MOQ: 1 Set

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

BOBIG

Model Number:

Fujian Bobig Electric Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FUZHOU

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name BOBIG

Model Number GF

Output Type Other, AC Three Phase, AC 3 Phase

Speed 1500/1800rpm

Frequency 50HZ/60HZ

Rated Power 8kw to 1000kw

Rated Voltage 220,230,240 ,400,440,380V

Rated Current 14.4A to 1800A

Specifications

DUETZ GENERATORS
Deutz Cummins Lovol China engine
Stamford,LEROY-SOMER aternator
8kw to 1000kw
Silent or op

DUETZ GENERATORS

MAIN SPECIFICATION
Model		GF3-100
Power(kw/kva)		100(125)
ENGINE	Engine Model	TBD226B-6D
	Rated Output(KW)	120
	Max Output(KW)	132
	Starting method	Electric starting
	Cooling method	Closed water cooled
	Governing method	Mechanical
	Intaking method	Natural apirated
	Cylinder numbers	6
	Fuel consumption(g/kw.h)	≤205
	Bore/stroke(mm)	105/120
	Displacement(L)	6.23
	Oil volume(L)	13
	Type	Water cooling, in-line, four-stroke, humid cylinder liner,direct injection
	Crankshaft rotation direction	Counterclockwise(face to output end)
ALTERNATOR	Model	274D
	Rated Output(KW)(KVA)	100(125)
	Rated Voltage(V)	400/230V
	Frequency(HZ)	50/60
	Power Factor	0.8 lagging
	Phase/Connection	3-phase 4-wire Y-type connection
	Excitation	Harmonic or Brushless Excitation
	Voltage Regulation	Manual/Automatic
Net Weight(kg)		1300kg
Dimension(mm)		2.40.821.75m

Terms & conditions:
Packing: plywood
Warranty: 12 months or 1500hours from the date of purchase whichever comes first,filter,belts,
gaskets,or some parts which are easy to consume is not included.
Production time: Within 40 working days depending on different powers and quantity
Term of Payment: 30% deposit before production, the balance shall be paid before delivery by T/T.
