Help Center300x300 15W Led Panel Light
Related Products
1. Light source: low power SMD LEDs (placed in the edge of the plate) Quick response when power on , no noise, no UV, no strobe light;
2. Adpot own-designed LED driver with high power factor;
3. Low luminous decay, Quick response when power on, long lifespan, no noise, no UV, no strobe light, no pollution;
4. Lightguide material : Acrylic lightguide board (guide light from four edges)
5. Color : Single color,bi-colour, RGB; (various colors available)
7. Installation : Convenient and efficient, both catenary and push-in type are available.
8. Certificate : TUV,CE, FCC, RoHS approved, with 3 year quality warranty.
PARAMETER
- Item NO.: GLM-AAAQ-X
- Dimension: 300mm x 300mm x 12mm
- LED type: SMD 2835
- LED Q'ty: 144pcs
- Material: Aluminium + PMMA
- Beam Way: Beam at two sides
- Working temperature: -10.C~40.C
- Installation method: Embedded.Hanging
- IP rate IP40
- N.W.(±0.1Kg) 1.3Kg
PHOTOELECTRICITY PARAMETER
- CCT .: 2900-6500K
- Flux.(±10%): 1400lm
- Light Efficiency(±10%): 70lm / Watt
- Input voltage: AC 110-240V
- Input Power: 18W
- CRI: Ra>80
- Lux.at 2Meters(±10%): 100lx
- Dimmable: Dimmable or Non Dimmable are available
- Lighting Angle: 120°
- PF: >9.0
TESTING REPORT FOR 15W LED PANEL LIGHT
APPLICATION
1. Commercial lighting, environmentally friendly lighting, warehouse , supermarket and home illumination.
2. IT, call centers, shopping malls and Exhibition Hall, art gallery, the hospital hotel and other public places.
3. Exhibition Hall, art galleries, museums, offices, reading-room, corridor, staircase lighting,such as contour range
NOTE
1,When installation LED panel light, try to avoid the minefields, strong magnetic field and high-pressure region.
2,Ensuring a solid connection correctly in order to avoid short-circuit damage to components and trigger fires.
3,Installed in a well-ventilated place to ensure appropriate environmental temperature.
4,Using the led panel light, please check the local voltage compliance product requirements.
5,To prohibit the live wiring, check to confirm wiring is correct, check the no short-circuit, and then power!
6,In case of failures, do not maintenance in private.
