Remote pressure gauge resistance
Description:
YTNZ-150 pressure gauge with resistance transmitter with good vibration resistance, suitable for medium mechanical vibration and pulsation working environment.
YTNZ-150 resistance Locator pressure gauge by remote sensors installed inside the instrument measured value is transmitted to the measuring point away from the secondary instrument to achieve centralized monitoring and remote control, in addition, remote pressure gauge resistance place simultaneously indicated pressure, easy on-site inspection process.
Technical Parameters:
Dial diameter: 150mm
Accuracy: 1.6
Initial resistance value sent: 3 ~ 20Ω
Transmitter full scale resistance value: 340 ~ 400Ω
Transmitter terminals applied voltage is not greater than 6V
Slip resistance transmitter wiring diagram
Oil-filled media: silicone
Environmental Conditions: -40 ~ 60 °C, relative humidity less than 85%
Temperature effect: When the temperature deviation from 20 ± 5 °C, the temperature of the additional error of less than 0.4% / 10 °C.
Range:
Type |
range |
YTNZ-150 |
0~0.1;0~0.16;0~0.25;0~0.4;0~0.6;0~1;0~1.6;0~2.5;0~4;0~6;0~10;0~16;0~25;0~40 ;-0.1~0;-0.1~0.15;-0.1~0.3;-0.1~0.5;-0.1~0.9;-0.1~1.5;-0.1~2.4 |
