freon pressure gauge refrigerant
Technical data of freon pressure gauge refrigerant :
Meter diameter |
50mm(2inch) |
installing form |
Radial Install |
pressure range |
low pressure: 0~10Kg ,0~12Kg,0~15Kg -1~0~ 10Kg ,-1~0~ 15Kg high pressure: 0~35kg ,0~38kg ,0~40kg -1~0~35 Kg,-1~0~40 Kg |
joint thread |
50mm(2inch):M14*1.5orG1/4or1/4PT or7/16UNF 7/16UNF |
shell material |
Molded case, carbon steel of the lacquer that bake, iron shell plastic spraying and chrome plated iron shell, cast aluminum Stainless steel 1Cr18Ni9Ti,SUS304 |
level of protection |
IP64or as customer's requirement |
pointer material |
With molding with aluminium |
accuracy |
Under the condition of the meter : 50mm(2inch):2.5%f.s.or 1.6%f.s. 63mm(2.5inch):2.5%f.s.or 1.6%f.s. |
Sensitive element material |
Spring tube structure sensitive element material: Bronze, phosphor copper, stainless steel SUS304,SUS316,SUS316L |
||
machine core material |
Copper alloy, stainless steel SUS316 |
condition |
According to the instrument measurement medium, installation requirements |
joint material |
Copper alloy, stainless steel SUS316 |
||
scale base |
kgf/cm2,Mpa,Bar,kpa,Psi,cmHg, mmHg |
recognized |
GB1226-2000/ASME B40.1 |
dial material |
aluminium |
attached |
Certificate of approval, the directions for use |
Shield ring material |
Carbon steel of the lacquer that bake, shell plating chromium iron, stainless steel 1Cr18Ni9Ti(SUS304) |
relative humidity |
10%~80%(RH) |
mirrir material |
The force that press a gram, PC, glass, toughened glass, safety glass |
Filling medium (optional this spring tube structure only) |
Silicone oil (low viscosity) : general use -30~50°C Silicone oil (high viscosity) : high temperature use -20~60°C Glycerin (glycerin) : -10~50°C |
