Diaphragm vacuum pressure gauge
Description:
Diaphragm vacuum pressure gauge with diaphragm as a pressure sensor for measuring small. Measurement corrode copper alloy, non-explosive gas micro-pressure and negative pressure ventilation is widely used in boilers, other similar devices on gas piping, combustion devices.
Technical Parameters:
model |
structure type |
accuracy% |
measurement range(KPa) |
YE-100 |
Radial boundless |
±2.5 ±1.5
|
0~1.6;0~2.5;0~4; 0~6;0~10;0~16; 0~25;0~40;-1.6~0; -2.5~0;-4~0;-6~0; -10~0;-16~0;-25~0; -40~0;-0.8~0.8; -1.2~1.2;-2~2;-3~3; -5~5;-8~8;-12~12; -20~20 |
YE-100T |
Radial band behind |
||
YE-100Z |
Axial boundless |
||
YE-100ZT |
Axial with the front |
||
YE-150 |
Radial boundless |
||
YE-150T |
Radial band behind |
||
YE-150Z |
Axial boundless |
||
YE-150ZT |
Axial with the front |
||
remake: Special specifications can be customized. | |||
