Stainless steel Piston dead weight tester
Description:
JQ piston dead weight tester is our fourth generation product, this product is based on YS piston tester and KY piston tester, with a cost-effective, anti-off mechanism for piston systems, greatly reducing the harm caused by improper operation.
Specifications:
Measure range: 0.04`0.6MPa, 0.1`6MPa, 0.5`25MPa, 1`60MPa, 2`100MPa, 2`160MPa, 5`250MPa
Accuracy: 0.005, 0.01, 0.02, 0.05.
Function: used to calibrate digital pressure gauge, precision pressure gauge, pressure transmitter etc.
Material: tungsten carbide
Weight: No magnetic metal materials (0.005, 0.01, 0.02); carbon steel (0.05)
Features:
Item |
YS Series |
KY Series |
JQ Series |
Difference |
Material |
Alloy steel(hardness 28) |
Tungsten carbide (hardness 102) |
Tungsten carbide (hardness 102) |
Alloy is easy to wear, with big deformation coefficient, high error when high pressure Tungsten carbide with big hardness, small temperature coefficient, wear resistance, but brittle |
|
Anti-breaking device |
With guide rod for anti-breaking |
Without guide rod |
With guide rod for anti-breaking |
Anti-breaking device will reduce the piston fall time, but can protect the piston rob, more practical. |
|
Pre-pressurizing device |
No Pre-pressurizing device |
With Pre-pressurizing device |
Optional (electric pre-pressurizing) |
Pre-pressurized mainly used when the customer needs to connect more oil-filled pipes and equipment. Usually it does not require pre-pressurized. |
|
Displacement directions |
Scale displacement indications |
Digital displacement indications |
Scale displacement indication (Optional lighting instructions) |
Physical scale indication can be from the shackles of electricity, figure indicates more intuitive, both have their advantages, JQ type can have two kinds of instructions. |
|
Pressurization system |
Use traditional compression screw |
Self-lubricating pressurized cylinder without having to replace the sealing ring |
Small compression screw, need to replace the sealing ring, but with longer life |
Traditional screw pressurized system need more labour power. Self-lubricating pressurize is very easy Small caliber pressurized cylinder in the middle |
workbench |
Cast iron workbench |
Cast aluminum workbench |
Cast iron workbench |
Cast iron workbench with low cost and high hardness |
