Water oxygen dissolver



Description of Water oxygen dissolver :

XY - 4000 Water oxygen dissolver with microprocessor monitoring instrument online of water quality. The instrument configuration of the different types of dissolved oxygen electrode is widely used in power plants, petrochemical industry, metallurgy, electronics, mining, paper, fermentation, pharmaceutical, food and beverage, environmental protection water treatment, aquaculture, and other industry. For continuous monitoring of dissolved oxygen (do) value of the aqueous solution and temperature and control.

Features of Water oxygen dissolver :
1. LCD liquid crystal display screen
2. Manual/automatic temperature compensation
3. A variety of automatic calibration function
4. Two sets of relay control switch
5. High limit / / low limit / / hysteresis control
6. RS232 / RS485 communication connection
7. Double optional signal output current/voltage output
8. The same interface display value of dissolved oxygen and temperature
9. Set password to prevent non-work personnel wrong operation

Technical parameters of Water oxygen dissolver :



(1)  measuring range: Dissolved oxygen (do) : 0.0 ~ 200 (including g/L; 0.2 ~ 25.0 mg/L;

                                         The temperature: - 5 ~ 110.0 ℃;

(2)  the resolution: Dissolved oxygen: including 0.01 g/L; 0.01 mg/L;

                                   The temperature: 0.1 ℃;

(3)  the basic error: Dissolved oxygen (do) : + / - 0.2 (including g/LF, S; + / - 0.2 mg/LF, S;
                                   Temperature: + / - 0.3 ℃;
(4)  automatic or manual temperature compensation scope: 0 ~ 110 ℃
(5)  the residual signal electrode:  <1‰
(6)  the response time (final value 90%) : 25 ℃ when the < 60 s; At 35 ℃ < 30 s;
(7)  stability: Under the atmospheric temperature, drift every week < 2% f. S.
(8)  standard current or voltage output: The 0 ~ 10 ma (load resistance < 1.5 K Ω);
                                                                 4 ~ 20 ma (load resistance < 750 Ω);
                                                                    Optional: 0 ~ 5 VDC, 0 ~ 10 VDC, etc;
(9)  two sets of relay control contact: 3 a 240 vac, 6 a 28 VDC or 120 vac.
(10)  meter power supply: 220 vac plus or minus 10%, 50 + 1 hz, power 3 w or less;
                                            24 VDC power: 1 w or less;
                                           12 VDC power: 1 w or less;
(11)  instrument appearance size: 96 * 96 * 130 mm;
(12)  instrument installation: in tray (embedded);
           Installation hole size: 91 x 91 mm
(13)Electrode installation method: [ circulation type ] [ reaction kettle ]etc
(14)  optional features: / RS232 / RS485 communication interface connected to the computer
(15)  weight: 0.6 kg
(16)  Instrument working environment:  ambient temperature10 ~ 60 ℃:
                                                          Relative humidity: no more than 90%;
      In addition to the earth's magnetic field around without a strong magnetic field interference.
