Specifications
chlorine residual chlorine sensor analyzer meter1 professional manufacturer
2 high accuracy
chlorine residual chlorine sensor analyzer meter
Description:
XY-2000A Industrial chlorine-line water quality monitoring instrument is a microprocessor-controlled instrument. The instrument is widely used in drinking water treatment plants, drinking water distribution network, a swimming pool, water treatment works, sewage treatment, water disinfection (chlorine dioxide generator package) and other process industries, aqueous solution of chlorine and temperature values continuous monitoring and control.
Technical Parameters:
( 1 ) Measurement range ( can be set manually ) :
I chloride : 0 ~ 2.00mg / L (ppm);
0 ~ 5.00mg / L;
0 ~ 10.00mg / L;
0 ~ 20.00mg / L;
Temperature : -5 ~ 60.0 °C;
( 2 ) Resolution:
I Chlorine : 0.001mg / L; Temperature : 0.1 °C;
( 3 ) Basic error :
I Chlorine : ± 1% F • S; temperature : ± 0.3 °C;
( 4 ) Response time : 90% less than 90 seconds ;
( 5 ) pH compensation range : Manual pH compensation : 5 ~ 9pH;
( 6 ) isolated current output:
0 ~ 10mA ( load resistance <1.5KΩ);
4 ~ 20mA ( load resistance <750Ω);
( 7 ) two relay control contact : 3A 240VAC, 6A28VDC or 120VAC;
( 8 ) Instrument Power Supply:
220VAC ± 10%, 50 ± 1Hz, power ≤ 3W;
24VDC, Power : ≤ 1W ( optional ) ;
12VDC, Power : ≤ 1W ( optional ) ;
( 9 ) Instrument Dimensions : 96 × 96 × 130mm;
( 10 ) Meter Installation: panel mounting ( embedded ) ;
Installation hole size : 91 × 91mm;
Wall-mounted : 300 × 200 × 167mm;
( 11 ) Optional features:
RS485 / / RS232 communication interface connected to the computer ;
( 12 ) Instrument Weight : 0.6kg;
( 13 ) Instrument working environment:
Ambient temperature : -10 ~ 60 °C;
Relative humidity: less than 90% ;
In addition to the Earth's magnetic field without strong magnetic field around it. dust
Features:
LCD large-screen LCD
Chinese intelligent menu operation
A variety of automatic calibration function
Optional signal output
Manual, automatic temperature compensation
Manual pH value compensation
Two relay control switch
High limit and low limit, hysteresis control
RS485 / / RS232 communication connection optional
Same interface displays chlorine, PH and temperature values
Password protection is provided to prevent the misuse of non-staff steel
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this chlorine residual chlorine sensor analyzer meter , please visit the website
or contact skype:wangxiaoyuncalar
