high speed plastic powder SRL-Z500/1000 blending machine is applicable for mixing ,colouring and drying of various resin such as polyethylene,polypropylene,polyvinyl chloride etc and in the craft of engineering plastics such as ABS,polycarbonate etc before forming and processing as well as in the mixing of phenolic resin.
- high speed mixing motor inverter started
- high speed parts 3 methods temperature increasing: material self-friction/electric heating/conduction oil heating
- material discharge 2 methods: temperature controller automatic release/mixing time control
- the parts contact with raw material are all made of stainless steel 304 and mirror polishing treatment
- the barrel covers and three direct links made of cast aluminum
- the bearing chambers with special designs for the lubricating oil injection
- driving motor over current protection design
- PLC touch screen control system can be choosed for the high automatic control requirement
- special designed mixing axis design can avoiding the raw material leaking from the barrel
- mixing paddles after strict balance test.
Model |
SRL-Z100/200 |
SRL-Z200/500 |
SRL-Z300/600 |
SRL-Z500/1000 |
SRL-Z800/1600 |
Capacity |
200KG/HOUR |
350KG/HOUR |
500KG/HOUR |
1000KG/HOUR |
1500KG/HOUR |
Total Volume (L) |
100/200 |
200/500 |
300/600 |
500/1000 |
800/1600 |
Effective Volume(L) |
75/150 |
150/375 |
225/450 |
375/750 |
600/1200 |
Mixing Speed(rpm) |
650/1300/200 |
475/950/130 |
475/950/100 |
430/860/70 |
370/740/50 |
Heating/Cooling Method |
Electric/self-friction/recycling water |
||||
Mixing Time(minutes) |
8-12 |
8-12 |
8-12 |
8-15 |
8-15 |
DS Driving Motor(kw) |
14/22/7.5 |
30/42/7.5 |
40/55/11 |
47/67/15 |
80/110/22 |
Inverter Driving Motor(kw) |
22/7.5 |
45/7.5 |
55/11 |
75/15 |
110/22 |
Dimension(m) |
1.95X1.6X1.8 |
4.58X2.24X2.47 |
4.8X2.64X2.48 |
5.6X3X3.1 |
5.17X3.2X4.48 |
Weight(kg) |
2200 |
3400 |
3600 |
6500 |
9800 |
