Help Center2015 Hot Selling PVC Mixer Machine
Related Products
-
High Output PVC Blending EquipmentUS$ 5,500 - 5,600MOQ: 1 Set -
Cheap Price PVC Mixing Machine UnitUS$ 14,000 - 15,000MOQ: 1 Set
-
2015 New Made SRL-W800/2000 PVC Mixing UnitUS$ 12,500 - 18,000MOQ: 1 Set
-
SHR-500A PVC High Speed Mixer MachineUS$ 12,500 - 18,000MOQ: 1 Set
-
High Capacity PE+Wood Compound Mixing MachineUS$ 35,500 - 40,000MOQ: 1 Set
2015 hot selling PVC mixer machine specially designed for the plastic high speed mixing,drying, coloring.
- high speed mixing motor inverter started
- high speed parts 3 methods temperature increasing: material self-friction/electric heating/conduction oil heating
- material discharge 2 methods: temperature controller automatic release/mixing time control
- the parts contact with raw material are all made of stainless steel 304 and mirror polishing treatment
- the barrel covers and three direct links made of cast aluminum
- the bearing chambers with special designs for the lubricating oil injection
- driving motor over current protection design
- PLC touch screen control system can be choosed for the high automatic control requirement
- special designed mixing axis design can avoiding the raw material leaking from the barrel
- mixing paddles after strict balance test.
Model |
SRL-Z100/200 |
SRL-Z200/500 |
SRL-Z300/600 |
SRL-Z500/1000 |
SRL-Z800/1600 |
Capacity |
200KG/HOUR |
350KG/HOUR |
500KG/HOUR |
1000KG/HOUR |
1500KG/HOUR |
Total Volume (L) |
100/200 |
200/500 |
300/600 |
500/1000 |
800/1600 |
Effective Volume(L) |
75/150 |
150/375 |
225/450 |
375/750 |
600/1200 |
Mixing Speed(rpm) |
650/1300/200 |
475/950/130 |
475/950/100 |
430/860/70 |
370/740/50 |
Heating/Cooling Method |
Electric/self-friction/recycling water |
||||
Mixing Time(minutes) |
8-12 |
8-12 |
8-12 |
8-15 |
8-15 |
DS Driving Motor(kw) |
14/22/7.5 |
30/42/7.5 |
40/55/11 |
47/67/15 |
80/110/22 |
Inverter Driving Motor(kw) |
22/7.5 |
45/7.5 |
55/11 |
75/15 |
110/22 |
Dimension(m) |
1.95X1.6X1.8 |
4.58X2.24X2.47 |
4.8X2.64X2.48 |
5.6X3X3.1 |
5.17X3.2X4.48 |
Weight(kg) |
2200 |
3400 |
3600 |
6500 |
9800 |
--standard export packaging of poly-wooden cases or buble films.we suggest to purchase wooden cases ,if no ,we will fixed machines on containers walls with steel wires.
--by ship or train .
