plastic bottle water making machine

FOB Price

USD $20,000 - $25,000 / Set

1 Set(Min.Order)

Product Details

Condition:	New	Application:	Other, bottle,drum,jerry can,bumper,spoiler,water tank	Plastic Processed:	Other, PE , PP,PVC,PC,PA,ABS,PETG,TPU,EVOH,TPE,PPE etc.
Blow Moulding Type:	Extrusion Blow Moulding	Automatic:	Yes	Place of Origin:	Jiangsu, China
Brand Name:	longhua	Model Number:	LHB55D-2	Voltage:	220V 315V 380V 450V
Power(W):	5.5kw	Dimension(LWH):	2.92.12.5	Weight:	3.3ton
Certification:	CE,ISO9001	Warranty:	one year	After-sales Service Provided:	Engineers available to service machinery overseas

plastic bottle water making machine
a.fully automatic
b.hydraulic controlling
c.energy saving
d.easy operating

plastic bottle water making machine

It adopts advanced imported industrial control system from Japan Mitsubishi
The touching button can be chosen to be convenient in man-to-machine interaction
The machine running condition displays
The self-test function shows the condition of all of input and output points
PLD temperature computer-control
300 sets of mould parameters stored
Imported electric elements from Europe ,America and Japan

PLC Screw and Fan Die Head

Products produced by our machine

Our Achievements

Machine Parameters

Parameters
Specifications		LHB55D-2
Material		PC PP PVC PE ABS
Max container capacity	L	3.5
Number of die	set	1
Output(dry Cycle)	pc/hr	300/480
Machine Dimension(L×W×H)	M	2.92.12.5
Total weigh	T	3.3
Clamping Unit
Clamping force	KN	55
Platen opening stroke	mm	130*370
Platen size	mm	290*360
Max mould size(W×H)	mm	350*360
Mould thickness	mm	135*210
Power
Max drive	KW	5.5
Total power	KW	11.5
Air pressure	Mpa	0.6
Air consumption	m³min	0.2/0.4
Average energy consumption	KW	5.5
Extruder unit
Screw diameter	mm	55
Screw L/D ratio	L/D	24
Plasticising capacity	Kg/hr	45
Number of heating zone	zone	2
Extruder heating power	KW	7
Extruder driving power	KW	5.5
Die
Number of heating zone	zone	2
Power of die heating	KW	3
Max die-pin diameter	mm	60
Center distance of double die	mm	130
Center distance of tetra-die	mm	60

Hope we could have more chances to discuss the more details about the machine you want.

Also you will be very welcomed to visit us at any time.

Zhangjiagang Longhua Machinery Co., Ltd.: Contact nameabinliang chen; Phone86-512-58530838; AddressYongli Village, Leyu Town, Zhangjiagang
