Plastic Compounding Extruder

Name: Plastic Compounding Extruder
Brand: longhua
SKU: 108858237
Availability: InStock

US$ 29,000 - 30,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Other, bottle,drum,jerry can,bumper,spoiler,water tank

Plastic Processed:

Other, PE , PP,PVC,PC,PA,ABS,PETG,TPU,EVOH,TPE,PPE etc.

Zhangjiagang Longhua Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Other, bottle,drum,jerry can,bumper,spoiler,water tank

Plastic Processed Other, PE , PP,PVC,PC,PA,ABS,PETG,TPU,EVOH,TPE,PPE etc.

Blow Moulding Type Extrusion Blow Moulding

Automatic Yes

Place of Origin Jiangsu, China

Brand Name longhua

Model Number LHB75D-4

Voltage 220V 315V 380V 450V

Power(W) 7.5kw

Dimension(L*W*H) 3.4*2.2*2.5

Weight 4.7ton

Certification CE,ISO9001

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

plastic compounding extruder
a.fully automatic
b.hydraulic controlling
c.energy saving
d.easy operating

plastic compounding extruder

It adopts advanced imported industrial control system from Japan Mitsubishi
The touching button can be chosen to be convenient in man-to-machine interaction
The machine running condition displays
The self-test function shows the condition of all of input and output points
PLD temperature computer-control
300 sets of mould parameters stored
Imported electric elements from Europe ,America and Japan

PLC Screw and Fan Die Head

Products produced by our machine

Our Achievements

Machine Parameters:

Machine Model		unit	LHB75D
Max. Product Capacity		L	1.25
Output		Pc/hr	1200-1800
Extruding System	Screw Diameter	mm	75
	Screw L/D Ratio		24
	Extruding Power	Kw	22
	No. of Heaters		3
	Screw Heating Power	Kw	11.1
	HDPE Plasticising Capapcity	Kg/Hr	56
Single Die Head	Max. Die-pin Diameter	mm	135
	Number of Heating Zone		3
	Heating Power of Die Head	Kw	4.4
Tri-die Head	Center Distance of Die Head	mm	110
	Max. Die-pin Diameter	mm	55
	Number of Heating Zone		4
	Heating Power of Die Head	Kw	6.5
Tetra-die Head	Center Distance of Die Head	mm	85
	Max. Die-pin Diameter	mm	30
	Number of Heating Zone		5
	Heating Power of Die Head	Kw	6.5
Clamping System	Clamping Force	KN	65
	Platen Size	mm	290*360
	Platen Opening Stroke	mm	150-500
	Max. Mould Size	mm	350*360
	Mould Thickness	mm	155-300
Power	Total Power	Kw	42.5
	Average Power consumption	Kw	26
	Air Pressure	bar	0.6
	Air consumption	m3/min	0.4/0.8
	Cooling Water Pressure	bar	3
	Cooling Water Consumption	m3/Hr	3/6
Machine dimension		m	3.42.22.5
Machine Weight		T	4.7
