GP series Double Air Flue and Forced Convection Drying Oven/ Incubator
Main Picture
Characteristic for model B and model BE
High accuracy, high efficiency, good safety and wide application.
Easy operation: running with data set and time set, and automatic shutdown. PID controller controls temperature accurately.
Special function key for temperature setting.
Auxiliary menu makes over-temperature alarm, deviation calibration, and menu buttons lock come true.
Vertical double air flue air-casing, forced air convection, better temperature conformity.
Adjust speed fan motor makes it easy to dry lightweight tiny powder sample.
Forced air intake structure for fan motor cooling ensures its max working temperature less than 50℃ which lengthen the service life of fan motor.
Special characteristic for model BE
Multiple data is displayed in the LCD screen at the same time, power outage compensation
Over-temperature protector
Specifications
| Model | GP-30B | GP-45B | GP-65B | GP-125B | GP-230B | |
| GP-30BE | GP-45BE | GP-65BE | GP-125BE | GP-230BE | ||
| Application | used for drying, baking, thermal treatment and bacteria culturing | |||||
| Air circulation type | double air flue and forced convection | |||||
| Performance | temp. range | RT+5~80℃(culturing); 80~250℃(drying) | ||||
| temp. resolution | 0.1℃ | |||||
| temp. fluctuation | ±0.5℃(culturing); ±1℃(drying) | |||||
| temp. uniformity | ±1.0℃(culturing); ±2.5%(drying) | |||||
| Structure | chamber material | stainless steel | ||||
| shell material | spraying cold rolled steel | |||||
| thermal insulation material | aluminum silicate fiber | |||||
| heating device | stainless steel heating tube | |||||
| rated power(culturing) | 0.3kw | 0.3kw | 0.4kw | 0.6kw | 0.7kw | |
| rated power(drying) | 0.8kw | 1.2kw | 1.6kw | 2.3kw | 3.0kw | |
| vent | φ28mm*1(top) | φ28mm*2(top) | ||||
| Controller | temp. control | model B: double rows of digital tubes,PID;model BE: double rows of LCD,PID | ||||
| temp. setting | press the four keys slightly | |||||
| temp. display | model B actual temp.:displayed by 4 digit digital tube (row 1); | |||||
| setting temp.:displayed by 4 digit digital tube (row 2). | ||||||
| BE type: actual temp.:display by LCD (row 1);setting temp.:display by row 2. | ||||||
| timer | 0~9999 minutes (with timing function) | |||||
| operation function | running with data set and time set, and automatic shutdown based on setting | |||||
| program mode | optional | |||||
| sensor | Pt100 | |||||
| additional function | deviation adjustment, menus and buttons lock, automatic recovery to previous status after power outage and recovery | |||||
| speed adjustable fan | fixed speed fan | |||||
| Safety device | B and BE model: over-temperature alarm; | |||||
| BE model: over-temperature protector. | ||||||
| Specification |
working size (W*D*Hmm) |
310*310*310 | 350*350*350 | 400*360*450 | 500*450*550 | 600*500*750 |
|
exterior size (W*D*Hmm) |
460*510*695 | 500*550*735 | 550*550*840 | 636*680*915 | 730*670*1220 | |
|
packing size (W*D*Hmm) |
550*570*765 | 620*585*800 | 640*640*905 | 730*720*1000 | 900*800*1350 | |
| working capacity | 30L | 45L | 65L | 125L | 230L | |
| shelf load bearing | 15kg | |||||
| max shelf layer | 6 layers | 7 layers | 9 layers | 13 layers | 17 layers | |
| height between shelves | 35mm | |||||
| Power source ( 50/60Hz)/Rated current | AC220V/3.6A | AC220V/5.5A | AC220V/7.2A | AC220V/10.5A | AC220V/13.6A | |
| NW/GW | 33/37 | 37/43 | 44/49 | 60/66 | 94/120 | |
| Accessory | shelf | 2pcs | ||||
| shelf bracket | 4pcs | |||||
| Optional device | shelf, RS485 port, printer, recorder, external communication, remote control, program temperature controller, wireless message alert, U disk storage. | |||||
