China distribuidores de rodamientos 2307EKTN9 ball bearing manufacturers
The outer ring raceway of self-aligning ball bearings forms a spherical surface whose center is common to the bearing center. The inner ring of the bearing has two raceways. The balls, cage, and inner ring of these bearings are capable of a shifting in order to compensate ofr a certain degree of misalignment with the outer rings. As a result, the bearing is able to align itself and compensate for shaft / housing finishing uneverness, bearing fitting error, and other sources of misalignment.
- Self aligning ball bearngs use pressed cages wiht the exception of the 1200-1206 series which use molded resin cages. The material characteristics of hte resin cages make them unsuitable for use in applications where temperatures exceed 120°C.
- Listed below are the allowable misalignment angles for bearings with selfaligning characteristics when placed under normal load conditions. This degree of allowable misalignment may be limitecd by the design of structures around the bearing.
- Allowable misalignment under normal loads (loads equivalent to 0.09 Cr); 0.07 rad (4°)
Product details:
1 |
Item No |
2307EKTN9 |
2 |
Sample |
Free |
3 |
Deilivery time |
Within 1-3 days |
4 |
Material |
Bearing steel Gcr15 and Carbon steel is also available |
5 |
Cage Material |
Steel ,Brass |
6 |
Precision rating |
P0 P6 P5 P4 P2 |
8 |
Quality Standard |
ISO9001:2000 |
9 |
OEM service |
YES |
10 |
Packing |
|
11 |
Application |
Steel, cement industry, mining&construction, paper making machinery, rolling mill, sugar mill, vibration screens, conveyors, air blower, transmissions, oil industry and other heavy machines. |
12 |
Other types we supply |
Deep groove ball bearing, self-aligning ball bearings, cylindrical roller bearings, spherical roller bearing, tapered roller bearing, thrust ball bearing. |
Other types
Item No |
ID(mm) |
OD(mm) |
Thickness(mm) |
Grease(r/min) |
Oil(r/min) |
Wight(kg) |
1204K+H204 |
20 |
47 |
40 |
14000 |
17000 |
0.19 |
1205K+H205 |
25 |
52 |
44 |
12000 |
14000 |
0.27 |
1206K+H206 |
30 |
62 |
48 |
9900 |
12000 |
0.36 |
1207K+H207 |
35 |
72 |
52 |
8500 |
10000 |
0.56 |
1208K+H208 |
40 |
80 |
56 |
7500 |
9200 |
0.73 |
1209K+H209 |
45 |
85 |
58 |
7000 |
8500 |
0.79 |
1210K+H210 |
50 |
90 |
58 |
6500 |
7900 |
0.88 |
1211K+H211 |
55 |
100 |
60 |
5800 |
7100 |
1.16 |
1212K+H212 |
60 |
110 |
62 |
5200 |
6400 |
1.52 |
1304K+H304 |
20 |
52 |
44 |
13000 |
15000 |
0.27 |
1305K+H305 |
20 |
62 |
48 |
9900 |
12000 |
0.45 |
1306K+H306 |
30 |
72 |
52 |
8700 |
11000 |
0.61 |
1307K+H307 |
35 |
80 |
56 |
7600 |
9300 |
0.82 |
1308K+H308 |
40 |
90 |
58 |
6900 |
8400 |
1.09 |
1309K+H309 |
45 |
100 |
60 |
6100 |
7500 |
1.40 |
1310K+H310 |
50 |
110 |
62 |
5600 |
6800 |
1.74 |
1. For small ones:anti-rust oil+vacuum plastic bag+paper box+wooden box
2. For big ones:anti-rust oil+waterproof belt+professional belt+wooden box
Payment Terms:
L/C ,T/T ,western Union
1. 30% deposit By T/T, Western Union, Paypal, 70% before delivery.
2. 100% L/C at sight
Other information:
Production Lead time: 7~25days; If we have this item in stock , 2days delivery.
Delivery Date: within 3-5days after your payment.
Sample: Free, but we don't bear the freight of sample
MOQ: 1 set Supply Ablility:100000 pcs/Month
Company Introduction |
Shanghai Shengyue Bearing Co.,ltd is a professional bearing manufacturer and dealer in china.We have been engaged in bearing industry for 12 years and made international trade of bearing import and export for more than 5 years.We attend international bearing fairs, put in many B2B website and achieve many customers all over the world also bulid up good reputation from our customers. |
||
Fixed telephone |
86-021-60700372 |
Fax |
86-021-60700373 |
Why buy from us?
1.Highest quality and most competitive price----we are the only one manufacture who adopts import raw materials. Low bad rates, is just 0.1%. It is amazing, and with cheap price and guaranteed quality.
2.Delivery fast -----Goods be sent out within 7 to 15 days based on order quantity.
3.Professional-----We are special in source and sells, as development, methods, conjugations, and handling.
4.Best service-----Answering e-mails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
