Product Details
| Condition | New | Product Type | Toilet Tissue | |
| Processing Type | Paper Slitting and Rewinding Machine | Place of Origin | Fujian, China | |
| Brand Name | Huaxun Machinery | Model Number | HX-1575B | |
| Voltage | 380V 50HZ | Power(W) | 11.3KW | |
| Dimension(L*W*H) | 5800 *2600 *1800 mm | Weight | 6T | |
| Certification | CE | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Automatic embossed perforating toilet paper roll making machine supplier
Video link: https://youtu.be/GdnGCtWfeME
This equipment has been integrated with the internationally advanced PLC technology. It has variable speed adjustment and touch human-machine interface operating system. It adopts newly designed glue applicator unit which makes the gluing more uniform. It can add 1-3 colors’ water ink printing system for printing diversified fine pattern, brand which is with characters of clear and bright printing, exact overprint, high speed and stable running.
Production process:
kitchen towel: unwinding of jumbo roll--embossing --glue lamination--perforation--rewinding--trimming finished kitchen towel roll and spraying glue one it
toilet paper: unwinding of jumbo roll--embossing--perforation--rewinding--trimming finished toilet roll and spraying glue one it
1. Adopts PLC programmable controller to control the production program.
2. Paper core replacement and rewinding without stop, spraying glue and cutting paper carry through automatically and sequentially
3. The rewinding process of the product is tight first and loose afterward, with its tension adjustable.
4. Can produce paper roll with core or without core
5. Can add paper core automatically, machine stop when paper core using up.
6. Machine stop when raw paper broke.
7. Paper tension control when unwinding jumbo roll.
8. Jumbo Roll Paper is pneumatically uploaded onto machine (this machine with two jumbo roll stands)
9. From jumbo roll to cut, just need one worker to operate.
Main technical parameter for rewinding machine:
1.production speed:about 120-180M/min
2.Finished roll diameter: 100-130 MM ;
3.Finished roll width:toilet paper 90-120 MM
4.Jumbo roll paper request: double plies 13-20g/m2;single plies 20-40 g/m
5.Perforating distance: toilet paper 100-150 MM
6.Jumbo roll width: 1800MM.
7.Jumbo roll diameter: 1200MM;
8.Jumbo roll weight: 800KGS. Other weight can be customized
9.Equipment overall size(L * W * H): 6630*3600*1900MM
10.Equipment power:about 15.3KW(380V 50HZ)
11.Equipment weight:about 7T
Main technical parameter for log saw machine:
1,Log length:1500~2000mm(according to customer request)
2,Log diameter:φ100~φ130mm (can be customized)
3,Production speed:cutting times 80~100 cut/min×2rolls
4,Equipment power: 6.77KW(380V 50HZ)
5,Equipment weight:about 2T
6,Equipment overall size(L * W * H):8500*1200*1920MM
1.The seller will send one engineer for installation, start up and training on the operations in the buyer’s plant. The buyer will be responsible for the two-way air tickets, transportations, accommodations and meals during their stay, plus 80$ per day for allowance. Also, the buyer should provide all the necessary means and personnel to help on the installation and start up of the machinery.
2. The seller will always provide long term service on technology.
Quanzhou Huaxun Machinery Making Co.,Ltd. is an enterprise specialising in manufacturing disposable living goods machinery,this company integrates research and development,manufacture and sale,product widely covers all kinds of toilet paper,babydiaper,women sanitary napkin and sanitary pad,etc living paper equipment. Our company has already researched and developed and manufactured new type of equipments for many enterprises both in China and abroad successfully.
Your satisfaction is our goal,we will try our best to give you the best service,so for any suggestion,will be very appreciated.Have any questions,feel free to contact us,will reply you asap.
