Semi-electric Order Picker(TH Series)

Semi-electric Order Picker(TH Series) thumbnail-1
Semi-electric Order Picker(TH Series) thumbnail-2
Semi-electric Order Picker(TH Series) thumbnail-3
Semi-electric Order Picker(TH Series) thumbnail-4
Semi-electric Order Picker(TH Series) photo-1
Semi-electric Order Picker(TH Series) photo-2
Semi-electric Order Picker(TH Series) photo-3
Semi-electric Order Picker(TH Series) photo-4
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
MIMA
Contact Supplier Request Quote Chat Now
Hefei Banyitong Science & Technology Developing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Anhui, China
Brand Name MIMA
Model Number TH
Type Powered Pallet Truck
Power Souce Other, electric lift
Rated Loading Capacity 300kg
Max. Lifting Height 3500mm
Min. Lifting Height 2400mm
Certification CE,ISO,SGS
After-sales Service Provided Overseas third-party support available

Specifications

Rated load capacity: 300kg;
Max lift height: 3500mm, usualy used in warehouse, library, supermarket rack etc

Description
Model No.
TH0324
TH0330
Operation Type
Stand-on
Stand-on
Rated Load Capacity (KG)
300
300
Max Lift Height (mm)--H
2400
3000
Max.Height-Rack (mm)--H1
3710
4010
Max.Height-Max (mm)--H2
2920
3220
Height-Mast Lowered(mm)-H3
1690
1990
Min.Height-Platform(mm)-H4
540
540
Min. Height-Stand Platform(mm)-H5
345
Min. Road Clearance (mm)-H6
195
Overall Length (mm)--L
1520
Wheelbase (mm)--L1
1025
Overall Width (mm)--W
890
Rear Tread (mm)--W1
686
Front Tread (mm)--W2
485
Body Width (mm) --W3
600
Front Wheel (mm)
150*50
Rear Wheel (mm)
180*50
Load Platform Size(mm)
600*600
Stand Platform Size(mm)
450*600
Min. Turning Radius(mm)Ra
1380
Lift Speed(mm/s)
85
Lift Motor
1.5
Battery-V/AH
12/120
