Help CenterMILLI-VOLT METER
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
TC
Model Number:
TC22A
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI OR NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
TC
Model Number
TC22A
Display Type
Analog Only
Measuring Range
Measurement Voltage Range: 800uV - 10V
Accuracy Class
Inherent error: ≤ ± 2%:
Dimensions
140*166*240
Specifications
the ultra-high frequency milli-volt meter.linear scale, high accuracy measurement. stable performance.
Introduction
TC22A, the ultra-high frequency milli-voltage meter can measure Sine waveform voltage from 20KHz to 1000MHz band. It’s measurement capability ranges from 800µV to 10V, which measurement range can be expanded to 300V when add one divider voltage.
Features:
1. Linear scale, high accuracy measurement, no need adjusted one step by one step and self-alibration. Stable performance.
2. Measurement range can be scalable.
Main technical specifications
- Input Voltage Range: 800µV - 10V, ( can be expanded to 300v if add divider voltage
- Input decibel range: -40dB~30dB8 steps
- Voltage accuracy (Reference 100kHz): ± 3% full scale (less than 10Mv); ± 3% full scale (above 10Mv)
4. Frequency response (Reference 100kHz):± 3%( 100kHz ~ 50MHz); ±10% (200kHz ~ 600MHz), 15% (600MHz ~ 1000MHz)
5. Decibel accuracy (Reference 100kHz): ±2.5dB (above 10 dB), ±3.5dB (less than 10 dB); ±5dB (less than -20 dB);
- Input capacity: ≤ ± 2.5pF
- SWR of coaxial T adapter : ≤ ± 1.35( 1000MHz)
- Power supply: 110~127VAC ±10% / 220~240VAC ±10%, 50Hz± 2Hz/ 60Hz±2Hz
- Weight: 2.5kgs
- Dimensions (WXHXD): 140mm X 166mm X 240mm
- Inherent error: ≤ ± 2%:
- Frenquency range: 20KHz~1000MHz
