300/500V4mm2 PVC Coated PVC Sheathed Wires to BS 6004

Name: 300/500V4mm2 PVC Coated PVC Sheathed Wires to BS 6004
Brand: JYTOP
SKU: 108163131
Availability: InStock

US$ 0.6 - 9 MOQ: 100 Meters

Key Specifications

Place of Origin:

Henan, China

Brand Name:

JYTOP

Model Number:

4mm2 PVC coated wire BS 6004

Zhengzhou Jinyuan Wire And Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Main Ports of China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name JYTOP

Model Number 4mm2 PVC coated wire BS 6004

Type Insulated

Application Other, General purpose

Conductor Material Copper

Conductor Type Other, Stranded or Solid

Insulation Material PVC

Specifications

300/500V 4mm2 PVC coated wire BS 6004
Reference No 6242y
Flat-Twin with Bare Earth-continuity Conductor

Reference No 6242y

Flat-Twin with Bare Earth-continuity Conductor

1.Conductor of high conductivity copper wires insulated with PVC compound.

Sheathed with PVC compound

2.Core colors: red and black

Sheath colors: grey or white.

Size of conductor		Nominal thickness of insulation mm	Size of earth conductivity conductor no./mm	Nominal thickness of sheath mm	Mean overall dimensions		Approx. net weight per km kg
Nominal cross- sectional area mm²	Number and diameter of wires mm	Nominal thickness of insulation mm	Size of earth conductivity conductor no./mm	Nominal thickness of sheath mm	Lower limit mm	Upper limit mm	Approx. net weight per km kg
1.0	1/1.13	0.6	1/1.13	0.9	4.0*7.2	4.7*8.6	70
1.5	1/1.38	0.7	1/1.13	0.9	4.4*8.2	5.4*9.6	85
2.5	1/1.78	0.8	1/1.13	1.0	5.2*9.4	6.2*11.0	120
4	7/0.85	0.8	1/1.38	1.0	5.6*10.5	7.2*13.0	175
6	7/1.04	0.8	1/1.78	1.1	6.4*12.5	8.0*15.0	240
10	7/1.35	1.0	7/0.85	1.2	7.8*15.5	9.6*19.0	390
16	7/1.70	1.0	7/1.04	1.3	9.0*18	11.0*22.0	560
